TDK Corporation VLS5045EX1R0NH Automotive Power Inductor
The VLS5045EX-H series are magnetic shield wound inductors designed for automotive power circuitry, including ECMs, airbags, headlights, and electronic power steering. Featuring high magnetic shield construction with ferrite cores, these inductors offer high current capacity, low Rdc, and reliable performance over -40 to +125°C. Compliant with AEC-Q200 standards, they are suited for demanding automotive environments, ensuring durability and stability in critical electronic modules.
TDK Corporation VLS5045EX1R0NH Automotive Power Inductor Specifications:
- Dimensions: 5.35 x 5.65 x 4.47 mm
- Operating temperature range: -40 to +125°C
- Storage temperature range: -40 to +125°C
- Inductance values: 1.0 to 220 µH
- Rated current: 0.015 to 1.05 A
- DC resistance: 0.015 to 0.58 Ω
- Operating frequency: 100 kHz
- Magnetic shield type wound inductor
- Material: Ferrite core
- Compliance: AEC-Q200
- Max current parameters: ISAT 8.9 to 0.45 A, Itemp 5.1 to 0.45 A
- Soldering profile: Peak 250°C for 40s, preheat 60-120s at 60-120°C
- Packaging: 1500 pieces per reel
- Applications: Automotive ECM, airbags, headlights, power steering, ABS
Buy the Automotive Series VLS-EX-H Inductor: VLS5045EX1R0NH
Purchase VLS5045EX-H series automotive power inductors online today. Designed for high-current power circuits, these inductors feature ferrite cores, magnetic shielding, and compliance with strict automotive standards. Suitable for ECMs, airbags, headlights, and electronic power steering, they operate reliably from -40°C to +125°C. Their low DC resistance and high rated current ensure optimal circuit performance. Order now for fast delivery of high-quality inductors that deliver durability, stability, and performance in demanding automotive environments.
Get VLS5045EX-H inductors today—built for automotive power circuits with high reliability, low resistance, and temperature resilience.
Frequently Asked Questions
Where can I buy TDK Corporation VLS5045EX1R0NH?
You can click on the BUY or RFQ button to purchase VLS5045EX1R0NH from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part VLS5045EX1R0NH?
You can download the VLS5045EX1R0NH datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of VLS5045EX1R0NH?
TDK Corporation
