TDK Corporation VLS6045EX2R2NH Automotive Power Inductor
The VLS6045EX-H series offers high-performance wound ferrite inductors designed for automotive power circuits. Constructed with magnetic shielding and optimized ferrite cores, these inductors support high current applications with low Rdc. Compliant with AEC-Q200 standards, they are suitable for automotive equipment such as ECM, airbags, headlights, electronic power steering, and ABS systems. The series features various inductance values, rated currents, and dimensions, ensuring reliable performance under high-temperature conditions from -40°C to 125°C. Their compact size and high inductance stability make them ideal for dense electronic modules in automotive environments.
TDK Corporation VLS6045EX2R2NH Automotive Power Inductor Specifications:
- Series name: VLS6045
- Dimensions: 6.0x6.3 mm, typical height 4.7 mm
- Inductance range: 1.0 to 220 μH with tolerance ±30% to ±20%
- Rated current: up to 82 A for 15 μH, 12 A for 1 μH
- DC resistance: as low as 0.012 Ω for 1 μH
- Operating temperature: -40°C to 125°C
- Compliance: AEC-Q200
- Packaging: Reel with 1500 pcs, suitable for automatic insertion
- Material: Ferrite core with magnetic shield
- Application: Automotive electronics including ECM, airbags, headlights, electronic power steering, ABS
- Frequency characteristics: Up to 10 MHz, suitable for high-frequency power circuits
- Temperature range: -40°C to +125°C
- Measurement equipment: Keysight Technologies, Inc.
Buy the Buy Automotive Power Inductors Part Number VLS6045EX2R2NH Online
Secure your order for the automotive power inductor VLS6045EX2R2NH today. These high-quality ferrite inductors ensure stable inductance and low resistance for automotive control systems. With compliance to AEC-Q200 standards, they are ideal for ECUs, airbags, headlights, and ABS systems. The series supports high current applications with robust thermal performance at temperatures from -40°C to 125°C. Perfect for dense, high-frequency automotive power circuits, these inductors provide reliability, durability, and optimal electrical performance for automotive manufacturers and engineers seeking dependable electronic components.
Order your Automotive Power Inductors VLS6045EX2R2NH today and enhance your automotive electronic circuits with reliable, high-current inductors designed for demanding environments.
Frequently Asked Questions
Where can I buy TDK Corporation VLS6045EX2R2NH?
You can click on the BUY or RFQ button to purchase VLS6045EX2R2NH from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part VLS6045EX2R2NH?
You can download the VLS6045EX2R2NH datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of VLS6045EX2R2NH?
TDK Corporation
