TDK-LAMBDA DRB120243A0 Industrial Power Supply
The industrial 3-phase power supply provides 120W with adjustable 24V output voltage, wide input range, high efficiency, and transient protections. Suitable for automation, manufacturing, and communication systems, it features overload and short-circuit protection, remote ON/OFF, and compliance with IEC safety standards. Designed for DIN-rail mounting, it offers reliable performance in harsh environments with extensive certifications, including EMC and safety regulations. Perfect for demanding industrial applications requiring durable, compact power solutions with parallel and series operation capabilities.
TDK-LAMBDA DRB120243A0 Industrial Power Supply Specifications:
- Output Voltage: 24V DC, adjustable from 22.5V to 29V
- Output Current: Nominal 5A, Boost Max 6A/2s
- Input Voltage Range: 3x350VAC to 3x575VAC
- Power: 120W nominal, 144W boost for 2s
- Efficiency: Max 91.3%
- Inrush Current: Max 30/39A, Max Inrush Energy: 0.3/0.6A*s
- Hold-up Time: Min 23/43 ms
- Line Regulation: Max 0.1%, Load Regulation: Max 0.4%
- Protection: Overcurrent, Overvoltage, Short-circuit, Overtemperature
- Operating Temperature: -25°C to +55°C, with derating above 55°C
- Dimensions: Width 55mm, Height 129mm, Depth varies by terminal type (135.7mm or 138.2mm)
- Weight: 660g
- Certifications: IEC EN 61010-1, EMC standards, UL, CE, CB Scheme
- Enclosure: Aluminum, UL 94V-0 flammability
- Mounting: DIN-Rail IEC 60715 TH35-7.5/15
Buy the Buy TDK-Lambda Power Supply Part Number DRB120-24-3-A0 Online
Purchase the TDK-Lambda DRB120-24-3-A0 industrial 3-phase power supply online now. This 120W unit offers adjustable 24V output, high efficiency over 91%, and comprehensive protection features, making it ideal for automation, manufacturing, and communication systems. Its DIN-rail mount design ensures easy installation in harsh environments, supported by extensive safety and EMC certifications. Enjoy quick delivery and reliable performance, ensuring seamless operation for demanding industrial applications with durable, space-efficient power solutions that meet global standards.
Get TDK-Lambda DRB120-24-3-A0 today—built for industrial reliability, high efficiency, and transient protection in demanding environments.
Frequently Asked Questions
Where can I buy TDK-LAMBDA DRB120243A0?
You can click on the BUY or RFQ button to purchase DRB120243A0 from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part DRB120243A0?
You can download the DRB120243A0 datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of DRB120243A0?
TDK-LAMBDA
