TDK-LAMBDA DTM300PW480D2 medical power supply
The TDK Lambda DTM300PW480D2 is a 300W external power supply designed for medical and industrial applications, certified for safety standards including IEC60601-1 and IEC60601-1-2 Ed4:2014. It features a 48V output with 6.25A current, delivering reliable power with over 88% efficiency and low no-load consumption under 0.5W. The supply supports wide input voltage (90–264VAC) and operates from -30°C to +60°C, with robust protective features such as auto recovery overvoltage, overload, and short-circuit protection. Its compact size and multiple safety ratings make it ideal for medical device power management, ensuring safety, compliance, and dependable operation in demanding environments.
TDK-LAMBDA DTM300PW480D2 medical power supply Specifications:
- Input Voltage Range: 90 - 264VAC, 47 - 63Hz
- Output Voltage: 48V, Max Current: 6.25A, Power: 300W
- Efficiency: >88% at full load
- No Load Power Consumption: <0.5W
- Operating Temperature: -30°C to +60°C (derates from 100% to 70% load from 0°C to -30°C)
- Storage Temperature: -30°C to +85°C
- Dimensions: 112 x 222 x 45 mm
- Weight: approximately 1.57kg
- Safety Certifications: IEC/ES/CSA/EN60601-1, IEC/UL/CSA/EN60950-1, CE Mark
- EMC Compliance: EN55011, EN55024, FCC Part 15/18 (Class B)
- Isolation Ratings: 1.5kVAC input to ground, 4kVAC input to output, 4kVAC output to ground
- Protection Features: Auto-recovery overvoltage, overload, short-circuit protection
Buy the Lambda Series DTM300 48V Power Supply: DTM300PW480D2
Acquire the Lambda Series DTM300PW480D2 power supply now online for your medical devices and industrial systems. It offers high efficiency over 88%, wide input voltage range, and low power consumption under 0.5W at no load. Its compact design with dimensions of 112mm x 222mm x 45mm ensures easy integration into space-constrained environments. Certified to international safety standards including IEC60601-1, UL, and CE, this power supply guarantees safety, performance, and compliance. Perfect for critical applications requiring reliable power delivery and robust protection features.
Order your Lambda Series DTM300PW480D2 medical power supply today and ensure reliable, efficient power for your critical medical and industrial equipment.
Frequently Asked Questions
Where can I buy TDK-LAMBDA DTM300PW480D2?
You can click on the BUY or RFQ button to purchase DTM300PW480D2 from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part DTM300PW480D2?
You can download the DTM300PW480D2 datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of DTM300PW480D2?
TDK-LAMBDA
