TE CONNECTIVITY 22380171 Connector System
The VAL-U-LOK connector series with Terminal Position Assurance (TPA) is designed for secure, vibration-resistant connections in various electronic and electrical applications. These double row connectors accommodate up to 24 positions, rated at 600VAC and 9A per line. Made from UL 94 V-0 and glow wire compliant materials, they ensure high safety standards and compliance with IEC 60335-1. Suitable for household, industrial, and control system use, these connectors feature an integral lock latch and optional TPA devices to prevent contact back-out and enhance connection reliability, especially in vibration-prone environments.
TE CONNECTIVITY 22380171 Connector System Specifications:
- Positions: 2 to 24 (double row)
- Wire size: 26-18 AWG discrete wire
- Centerline pitch: 4.2 mm (.165 in)
- Operating temperature: -40°C to 105°C
- Voltage rating: 600V AC/DC
- Current rating: 9A per line
- Housing materials: UL 94 V-0 and UL 94 V-2 rated nylon, glow wire compliant with IEC 60335-1
- Contacts: Brass, pre-tin
- Intermateable with existing VAL-U-LOK products
- Suitable for wire-to-wire, wire-to-board, and wire-to-panel applications
Buy the TE Connectivity Series VAL-U-LOK: 22380171
Enhance your electrical projects with the TE Connectivity VAL-U-LOK connectors featuring Terminal Position Assurance. Designed for reliability, these connectors support up to 24 positions, rated at 600V and 9A, crafted from high-quality UL 94 V-0 and glow wire compliant materials. They feature integral locking latches and optional TPA devices that prevent contact back-out, ensuring secure, vibration-resistant connections in household, industrial, and control system applications. Perfect for wiring, panel mounting, and ensuring compliance with safety standards, order now for dependable performance.
Order your TE Connectivity Series VAL-U-LOK 22380171 connectors today and ensure secure, vibration-resistant connections for your electrical projects.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY 22380171?
You can click on the BUY or RFQ button to purchase 22380171 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part 22380171?
You can download the 22380171 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of 22380171?
TE CONNECTIVITY
