TE CONNECTIVITY ABC06N22S Aerospace Connectors
The ABC Series modular and in-line composite connectors are lightweight, environmentally sealed, and corrosion resistant, suitable for aerospace, defense, and marine applications. Available in two shell sizes with multiple insert options, these connectors offer over 4000 configuration possibilities. They feature high durability, resistance to hydraulic oil and jet fuel, and support up to 1500 mating cycles. Designed for space-saving stacking and panel mounting, they comply with aerospace flammability and toxicity standards, making them ideal for demanding industrial environments.
TE CONNECTIVITY ABC06N22S Aerospace Connectors Specifications:
- Shell Material: Nickel-plated composite (modular), Chemical-resistant PE composite (in-line)
- Seals: Fluorosilicone blend
- Inserts: Glass-filled thermoplastic
- Flammability: Meets aerospace requirements
- Temperature Range: -65°C to +175°C
- Humidity Resistance: Up to 98%, condensing
- Durability: 1500 mating cycles
- Shock Resistance: 100 g (half-sine @ 3 ms)
- Vibration Resistance: 4 grms
- Corrosion Resistance: >1000 hours salt spray
- Shielding: >40 dB from 100 to 1000 MHz
- Fluid Resistance: Suited for most aerospace fluids; optional hydraulic oil and jet fuel resistance
- Altitude capability: 75,000 ft.
- Physical Dimensions: Shell sizes 1” and 2”, acceptance of modules from 0.5” to 2”
- Mounting: Panel mountable, stackable for space efficiency
- Connector Cycles: Supports up to 1500 mating cycles
Buy the TE Series ABC Modular and In-Line Connectors: ABC06N22S
Discover TE’s lightweight aerospace connectors designed for demanding environments. The ABC Series offers modular, environmentally sealed, and corrosion-resistant interfaces with over 4000 configuration options. These connectors support high durability, fluid resistance, and space-saving stacking, making them ideal for aerospace, defense, and marine applications. Easy to mount and operate, they meet strict aerospace standards for flammability, toxicity, and environmental resilience. Ensure reliable connections in critical systems—order the TE ABC Series connectors online today to get superior performance and quality for your next project.
Order your TE Series ABC06N22S lightweight and durable aerospace connectors today and give your projects the dependable quality they deserve.
