TE CONNECTIVITY T2193501050000 High-Current Heavy Duty Connector
Heavy duty connectors from TE Connectivity are engineered for robust performance in demanding environments. The HCM series supports high current applications up to 650A, featuring IP68-rated housings made of durable aluminum alloy with salt spray resistance exceeding 500 hours. These connectors have modular contact configurations from 1 to 4 positions, suitable for data, power, or signal connections across industrial, outdoor, and power systems. They feature crimping contacts, stainless steel fasteners, and operating temperatures from -40°C to +125°C. The connectors comply with international standards, ensuring safety, reliability, and long-term service in harsh conditions.
TE CONNECTIVITY T2193501050000 High-Current Heavy Duty Connector Specifications:
- Current ratings: HCM250 - 250A, HCM350 - 350A, HCM650 - 650A
- Voltage withstand: HCM250 - 2000V, HCM350 - 2000V, HCM650 - 4000V
- Operating temperature: -40°C to +125°C
- Protection Degree: IP68 with salt spray resistance of 500 hours
- Housing Material: Aluminum alloy with powder coating
- Seals: Rubber, conductive rubber
- Fasteners: Stainless steel screw locking
- Insert configurations: 1-4 positions, crimping type
- Insert wire diameter: HCM250 - 35-70mm?, HCM350 - 35-120mm?, HCM650 - 35-240mm?
- Contact durability: Mating cycle > 500
- Standards: EN 61984, IEC 60068, IEC 60512, IEC 60529, IEC 60664-1, EN 61373
Buy the TE Series HCM High-Current Connectors: T2193501050000
Purchase the TE high-current heavy-duty connector now to ensure reliable power and signal connections in demanding industrial and outdoor applications. Designed with durable aluminum alloy housings, IP68 protection, and salt spray resistance exceeding 500 hours, these connectors support current ratings up to 650A with voltage withstand up to 4000V. The modular configurations from 1 to 4 positions, crimping contacts, and stainless steel fasteners make installation straightforward and secure. Ideal for power systems, rail, renewable energy, and harsh outdoor environments, ensuring long-lasting performance and safety.
Buy TE Connectivity high-current connectors T2193501050000 now and experience unmatched reliability and power handling in harsh industrial environments.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY T2193501050000?
You can click on the BUY or RFQ button to purchase T2193501050000 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part T2193501050000?
You can download the T2193501050000 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of T2193501050000?
TE CONNECTIVITY
