TE CONNECTIVITY T9AS5D225 Power Relay
The T9A Series is a versatile power relay designed for PCB or panel mount applications, rated for 30A switching, with options for dust-protected, wash-tight, or flux-proof enclosures. It features DC coil voltages from 5V to 110V, with contact configurations including normally open, normally closed, and changeover contacts. Suitable for HVAC, industrial controls, and appliance automation, it complies with UL 508 and CSA standards. The relay employs resilient contact materials like AgSnOInO and AgCdO, ensuring reliable operation across various load types and environmental conditions.
TE CONNECTIVITY T9AS5D225 Power Relay Specifications:
- Current Rating: 30A switching; 20A in form C (CO)
- Coil Voltage Range: 5 to 110VDC
- Coil Power: 900mW
- Contact Material: AgSnOInO, AgCdO
- Contact Arrangement: 1 form A (NO), 1 form C (CO), 1 form B (NC)
- Switching Voltage: Up to 277VAC
- Initial Dielectric Strength: 1500V between open contacts, 2500V between contact and coil
- Initial Surge Voltage: 6kV between contact and coil
- Ambient Temperature Range: -55°C to +85°C
- Enclosure Options: Open, dust protected, wash-tight, flux-proof
- Mounting: PCB or flanged with QC terminals
- Approvals: UL E58304, CSA LR48471
- Dimensions: Approximate 13.4 mm height, 6.35 mm terminal spacing, various mounting options
- Vibration Resistance: 10-55Hz, 1.65mm max excursions
- Shock Resistance: 10g functional, 100g destructive
- Compliance: RoHS, REACH, Halogen-free
Buy the TE Series T9A Power Relays: T9AS5D225
Secure your automation system with the TE Series Power Relay designed for high current switching up to 30A, featuring multiple enclosure options for environmental protection. Whether for HVAC, industrial controls, or appliances, this relay offers durable contact materials like AgSnOInO and AgCdO, ensuring dependable operation. Easy PCB or flange mounting options, UL and CSA approvals, and compact dimensions make installation straightforward. Buy online today to elevate your project’s reliability with a trusted component that meets rigorous safety standards.
Order your TE Series T9A power relay with 30A switching capacity today and ensure reliable performance for your industrial automation projects.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY T9AS5D225?
You can click on the BUY or RFQ button to purchase T9AS5D225 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part T9AS5D225?
You can download the T9AS5D225 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of T9AS5D225?
TE CONNECTIVITY
