TE CONNECTIVITY TLM2HDR024FTE Current Sense Resistor
This product is a low resistance metal chip resistor designed for current detection in power electronic systems. Constructed with metal foil for high reliability, it features a small size-to-power ratio and offers stable low and very low TCR. The resistor is supplied on tape and reel for automated assembly and is suitable for current sense circuits, ensuring accurate measurement and performance in demanding electronic applications. Its robust construction includes matte Sn over Ni terminal finish, with resistance values ranging from 10 mΩ to 100 mΩ and power ratings up to 1 watt.
TE CONNECTIVITY TLM2HDR024FTE Current Sense Resistor Specifications:
- Power Rating: 0.125w (10-19 mΩ), 0.25w (20-100 mΩ), 0.5W (28-100 mΩ), 0.75W (2H series), 1W (3A series)
- Resistance Range: 10 mΩ to 100 mΩ
- Resistance Tolerance: ±1%, ±2%, ±5%
- Resistance Temperature Coefficient: Approximately 55°C to 125°C
- Terminal Finish: Matte Sn over Ni
- Construction: Metal foil, alloy resistor layer, alumina substrate
- Dimensions: Length approximately 1.0-6.3 mm; Width 0.85-3.15 mm; Thickness 0.15-0.40 mm
- Material: Copper (bottom electrode), nickel-chromium (top and edge electrodes), alloy resistor layer
- Environmental Tests: Short-term overload 5x rated power, endurance 1000 hours at max voltage, damp heat load, thermal shock, solderability ≥95%
- Operating Voltage: V = P * R; Overload Voltage: 2.5 * V; Operating Current: V / R
- Packaging: Tape and reel; quantities up to 5,000 units per reel; suitable for automatic insertion
- Standards: IEC 60115-1, JIS-C 5201-1
Buy the TE Connectivity Series TLM Metal Chip Resistor: TLM2HDR024FTE
Order the TE Connectivity TLM series current sense resistor online today. Designed for power electronics, it ensures precise current measurement with high reliability. Its robust metal foil construction provides low and stable TCR, making it ideal for current detection circuits. The resistor is supplied on tape and reel for easy automated assembly, with various resistance values and power ratings. Purchase now to ensure consistent performance in your electronic systems and experience fast, convenient delivery directly from authorized distributors.
Get TE Connectivity TLM2HDR024FTE today—built for precision, reliability, and high stability in power electronic current sensing applications.
