TE CONNECTIVITY TLR3A30DR002FTDG Low Ohmic Current Sense Resistor
The TLR Series are high power, low ohmic SMD current sense resistors designed for precise current measurement in automotive and power supply applications. These resistors offer power ratings up to 3 Watts at 80°C, come in tape packaging for easy handling, and feature a special metal resistive element with barrier layers to extend terminal life. They operate within -55°C to 170°C, enabling reliable sensing in demanding environments such as battery management systems and electronic control units, with resistance values suitable for sensitive current detection.
TE CONNECTIVITY TLR3A30DR002FTDG Low Ohmic Current Sense Resistor Specifications:
- Power Rating: Up to 3 Watt at 80°C
- Resistance Range: R001 - R0t, 0005 - ROIS
- Resistance Tolerance: ±3%, ±2.5%
- Operating Temperature: -55°C to 170°C
- Flammability: UL 94V-0 compatible
- Dimensions: 1206, 2010, 2512 (mm), with respective size ratings
- Inductance: Refer to testing chart for frequency response
- TCR: 50 to 135 ppm/°C depending on size
- Construction: Metal chip resistor with barrier layers
- Packaging: Tape for automated placement
Buy the Buy TE Connectivity TLR Series Part Number TLR3A30DR002FTDG Online
Purchase the TE Connectivity TLR Series low ohmic current sense resistor online and benefit from high power ratings up to 3 Watts, robust construction, and wide temperature tolerance. Ideal for automotive and electronic applications requiring accurate current detection, these resistors are supplied on tape for easy automation. Their special metal resistive elements and barrier layers ensure long terminal life and stable performance under demanding conditions. Order now to secure reliable, high-performance current sensing solutions for your power management systems.
Buy TE Connectivity TLR Series TLR3A30DR002FTDG now and experience reliable current sensing for automotive and power supply designs.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY TLR3A30DR002FTDG?
You can click on the BUY or RFQ button to purchase TLR3A30DR002FTDG from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part TLR3A30DR002FTDG?
You can download the TLR3A30DR002FTDG datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of TLR3A30DR002FTDG?
TE CONNECTIVITY
