The THD 10-4810WIN from Tracopower is a THD 10WIN series 10W DC to DC converter in 24 pin DIP package. The THD 10WIN series is designed for an optimized cost/performance ratio of DC to DC converters with output power of 10W. They come with an internal EMI-filter to meet EN55022, class A without external components. General features like no minimum load requirement, overload protection and high efficiency make these converters easy to design in. With the popular DIP-24 standard package they are also a drop in replacement for many cost critical applications.




Input voltage range from 18VDC to 75VDC (48VDC nominal)

Output voltage is 3.3VDC

Maximum output current is 2700mA

Typical efficiency is 86%

I/O isolation voltage is 1500VDC, typical I/O isolation capacitance is 1000pF

I/O isolation resistance is >1000Mohm at (500VDC)

Input current at no load is 20mA typical

Switching frequency is 330KHz, ultra-wide 4:1 input voltage range

Operating temperature range from -40°C to +85°C

UL/cUL 60950-1, IEC/EN 60950-1 safety standards





Applications


Industrial,

Communications & Networking,

Industrial
