TRACO POWER TEN254813WI DC/DC Converter Module
The TEN 25WI series offers high-performance DC/DC converter modules up to 30 Watt with an ultra-wide 4:1 input voltage range, adjustable output, remote On/Off, and multiple protection features. Designed for industrial electronics, communication systems, battery-powered devices, and distributed power systems, these converters comply with safety and EMI standards. They feature high efficiency up to 89%, a compact low-profile case, and excellent thermal performance. Optional heatsinks improve heat dissipation, making them reliable for demanding applications in challenging environments.
TRACO POWER TEN254813WI DC/DC Converter Module Specifications:
- Input Voltage Range: 3.3 VDC to 48 VDC
- Output Voltage: 3.3 V, 5 V, 12 V, 15 V, configurable via external resistor
- Output Power: Up to 30 Watts
- Efficiency: Up to 89%
- Input Current No Load: 10-20 mA
- Input Current Full Load: 920-1400 mA depending on model
- Isolation Voltage: 1500 VDC (Input/Output)
- Switching Frequency: 330 kHz
- Operating Temperature: -40°C to +85°C (derating applies)
- Humidity: Max 95% rel H
- Safety Standards: UL/cUL 60950-1, IEC/EN 60950-1
- Dimensions: Small low-profile case, weight approx. 56 g
- Remote On/Off: 2.5 to 100 VDC or open circuit, Off: 1.0 to +1.0 VDC
- Thermal Shutdown: 115°C
- MTBF: >550,000 hours
Buy the Traco Power TEN 25WI – Reliable DC-DC Converter for Industrial Applications
Enhance your industrial power systems with the Traco Power TEN 25WI series. These robust DC/DC converters deliver up to 30W with wide input ranges, adjustable outputs, and multiple protections, ensuring reliable performance even in demanding environments. Their high efficiency up to 89% minimizes energy loss, while optional heatsinks facilitate optimal thermal management. Ideal for industrial electronics, communication equipment, and battery-powered devices, these modules meet international safety and EMI standards, making them your go-to power solutions for all critical applications.
Buy Traco Power TEN 25WI now and experience unmatched reliability and high efficiency in industrial electronics and communication systems.
