TRACO POWER TMP30212C Industrial Power Module
The TMP30212C is a highly reliable AC/DC power module featuring a 12 VDC output with a maximum current of 2500 mA, designed for industrial control and electronic applications. Its compact, encapsulated design ensures dust and pollution resistance, suitable for harsh environments. It complies with international safety standards IEC/EN/UL 60950-1 and UL 508, offering high efficiency (up to 80%) and overload protection. The module operates at a broad input voltage range of 85-264 VAC with excellent regulation and low ripple, making it ideal for space-critical and rugged industrial projects.
TRACO POWER TMP30212C Industrial Power Module Specifications:
- Input Voltage: 85-264 VAC, 47-440 Hz
- Output Voltage: 12 VDC
- Output Current: 2500 mA
- Efficiency: Up to 80%
- Protection: Over-temperature, short circuit, overload
- Isolation Voltage: 3000 VAC (60 sec.)
- Operating Temperature Range: -25°C to +70°C with derating above 50°C
- Dimensions: 63.5 x 27.0 x 24 mm
- Casing Material: Plastic resin with fiberglass, UL 94V-0 rated
- Certifications: IEC/EN/UL 60950-1, UL 508
- MTBF: >330,000 hours
- Humidity: 95% RH max. (non-condensing)
- Switching Frequency: 100 kHz typ.
- Safety Standards: Compliance with IEC/EN 60950-1, UL 60950-1
Buy the Buy TracoPower TMP30212C Part Number TMP30212C Online
Purchase the TracoPower TMP30212C online today to benefit from its compact design, high efficiency, and reliable protection features. This 12 V power supply provides 2500 mA current, perfect for demanding industrial control and electronic applications. Its fully encapsulated plastic casing ensures durability in dusty and polluted environments, meeting international safety standards IEC/EN/UL 60950-1 and UL 508. With excellent regulation, low ripple, and a broad input voltage range, this module guarantees consistent performance and long MTBF, making it an excellent choice for critical automation systems and rugged equipment.
Order your TracoPower SeriesTMP30212C today and ensure reliable, space-saving power for your industrial control projects.
Frequently Asked Questions
Where can I buy TRACO POWER TMP30212C?
You can click on the BUY or RFQ button to purchase TMP30212C from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMP30212C?
You can download the TMP30212C datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMP30212C?
TRACO POWER
