TRACO POWER TMM60124C Power Module
The TMM 60 Series power supply modules deliver 60 Watts of reliable power with high efficiency, suitable for medical, industrial, and transportation applications. Fully encapsulated for durability, these units meet stringent safety standards including 2x MOPP medical safety, IEC/UL 60950-1, UL 508, and IEC/EN 60601-1. They operate across a wide temperature range of -40°C to +60°C, with derating up to 75°C. Features include over-temperature, overload, and short circuit protection, low no-load power consumption below 0.5W, and a 3-year warranty, ensuring safety and dependability in critical environments.
TRACO POWER TMM60124C Power Module Specifications:
- Output Power: 60 W
- Output Voltage/Current: 15 VDC / 4000 mA, 24 VDC / 2500 mA, 48 VDC / 1250 mA, 5.1 VDC / 10000 mA, 12 VDC / 5000 mA
- Efficiency: 84-88%
- Input Voltage Range: 100-240 VAC, 85-264 VAC, 120-370 VDC
- Input Frequency: 47-440 Hz
- Leakage Current: 80 pA typ.
- No-Load Power Consumption: <0.5 W
- Operating Temperature: -40°C to +60°C (derating up to 75°C at 50% load)
- Protection: Over-temperature, overload, short circuit
- Isolation Voltage: 4000 VAC
- Enclosure: Fully encapsulated, plastic resin (UL 94V-0)
- Dimensions: Length varies with version, typical unit size approximately 75 x 50 x 22 mm
- Reliability: >125,000 hours MTBF
- Certifications: UL 60950-1, IEC/EN 60950-1, IEC/EN 60601-1 3rd edition, UL 508
Buy the Traco Power TMM 60124C – Reliable Medical and Industrial Power Module for Critical Applications
Discover the high-performance TMM 60124C power module from Traco Power. Designed for medical, industrial, and transportation uses, this 60W power supply features rugged encapsulation, comprehensive safety certifications, and wide temperature operation from -40°C to +60°C. With high efficiency, low no-load power consumption, and extensive protection features including over-temperature and short circuit protection, it guarantees reliable operation in demanding environments. Ideal for critical applications that require safety, durability, and ease of integration. Order online now for quick delivery and unmatched quality.
Order your Traco Power TMM 60124C today and ensure your devices operate safely with high efficiency and robust protection features.
