TRACO POWER TEN402412WIN DC/DC Converter
The TEN 40WIN Series are high-performance 40-Watt isolated DC/DC converters designed for space-constrained applications in industrial, communication, and mobile equipment. Featuring an ultra-wide 4:1 input voltage range, efficiency up to 91%, and adjustable output voltage, these converters provide reliable power with protections against short circuit, over voltage, and overload. Operating in a temperature range of -40°C to +75°C, they support remote On/Off control, have safety certifications, and are suitable for distributed power architectures and instrumentation requiring compact, efficient solutions.
TRACO POWER TEN402412WIN DC/DC Converter Specifications:
- Input Voltage Range: 3.3 VDC to 48 VDC with models at 3.3 V, 5 V, 9-36 V, 12 V, 15 V, 24 V, and 48 VDC
- Output Voltage: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V (nominal) with adjustable range ±10%
- Maximum Output Current: 8,000 mA for 3.3 V and 5 V models, 3,330 mA for 12 V and 15 V models, 1,670 mA for 24 V models
- Efficiency: Up to 91% in some models
- Isolation Voltage: 1500 VDC
- Operating Temperature: -40°C to +75°C
- Protection: Short circuit, over voltage, over power
- Dimensions: 1.0” x 2.0” x 0.4” (25.4 x 50.8 x 10.2 mm)
- Weight: 30 g
- Switching Frequency: 320 kHz
- Safety Standards: UL, CSA, IEC 60950-1
- Remote On/Off Control: 4.7 to 12 VDC or open circuit for ON; 0 to 1.2 VDC or short circuit for OFF
- Environmental: RoHS compliant, reach compliant
Buy the Buy TRACOPOWER series DC/DC converter Part Number TEN402412WIN Online
Enhance your electronic system with the TRACOPOWER TEN402412WIN 40-Watt isolated DC/DC converter. Featuring a wide input voltage range, high efficiency up to 91%, and compact design, it is suitable for industrial, communication, and mobile equipment where space-saving reliable power is critical. It includes protections against short circuit, over voltage, and overload, operates efficiently over a broad temperature range, and supports remote On/Off control. Purchase online now for guaranteed quality and fast delivery to your project site.
Order your TRACOPOWER TEN402412WIN series 40 Watt high efficiency DC/DC converter today and ensure reliable power delivery for your industrial and communication projects.
Frequently Asked Questions
Where can I buy TRACO POWER TEN402412WIN?
You can click on the BUY or RFQ button to purchase TEN402412WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN402412WIN?
You can download the TEN402412WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN402412WIN?
TRACO POWER
