TRIAD MAGNETICS F28U Power Transformer
The F-28U power transformer is designed for reliable power management in industrial applications. It features a single secondary chassis mount with a maximum power capacity of 187.5 VA. The transformer operates with a primary voltage of 115V at 50/60 Hz and provides secondary voltages of 6.3VCT or 7.5VCT at 25.0 Amps. Constructed with UL recognized materials and wound on a nylon bobbin, it ensures safety with 3000V hipot testing between windings and core, making it suitable for demanding electronic systems requiring stable power output.
TRIAD MAGNETICS F28U Power Transformer Specifications:
- Maximum Power: 187.5 VA
- Primary Voltage: 115V 50/60 Hz
- Secondary Voltage: 6.3VCT or 7.5VCT @ 25.0 Amps
- Temperature Rise: 35°C typical (45°C max)
- Material: UL recognized, Class B rated (130°C)
- Wound on nylon bobbin
- Lead Length: 7.0 inches + 1 inch
- Dimensions: 4.625 x 3.812 x 3.062 inches
- Weight: 7.0 lbs
- Safety: 3000V hipot testing between windings and core
- RoHS Compliance: Yes, as of February 2005
Buy the Triad Series F-28U Power Transformer: F28U
Order the Triad F28U power transformer online today for dependable power management in industrial and electronic systems. Featuring a 187.5 VA capacity, UL recognition, dual secondary voltages of 6.3VCT or 7.5VCT, and robust safety testing, this transformer provides stable and efficient performance. Wound on a nylon bobbin and constructed with UL recognized materials, it ensures durability and safety in demanding environments. Perfect for applications requiring reliable power conversion with safety and certification standards met, making it an excellent choice for critical electronic applications.
Get Triad F28U power transformer today—designed for power management and industrial reliability.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS F28U?
You can click on the BUY or RFQ button to purchase F28U from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part F28U?
You can download the F28U datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of F28U?
TRIAD MAGNETICS
