TRIAD MAGNETICS N48X Isolation Power Transformer
The N-48X is an isolation power transformer designed to isolate equipment from direct connection to the power line. It features non-concentrically wound coils, with primary and secondary windings on separate arbors, assembled on a laminate core with insulation separation. This construction prevents electrical connection under normal or overload conditions. Rated for 115V primary voltage, it provides 1500V isolation between windings and the core, operating at 50/60Hz. Constructed for industrial environments with Class B insulation, it ensures safety and reliability in electrical systems.
TRIAD MAGNETICS N48X Isolation Power Transformer Specifications:
- Maximum Power: 15 VA
- Input Voltage: 115 V, 50 / 60 Hz
- Output Voltage: 115V +5%
- Full Secondary Load: 0.13 Amps RMS
- Voltage Regulation: 20 % TYP @ full load to no load
- Isolation Voltage: 1500V between windings and core
- Construction: Non-concentrically wound coils, separate arbors, laminate core
- Materials: Suitable for Class B insulation system
- Connections: 7.041” leads, color-coded for input and output
- RoHS Compliance: Meets 2011/65/EU standards
- Dimensions: N/A
- Frequency: 50/60Hz
- Tested: Hi-pot at 1500 VRMS
Buy the Triad N48X – Reliable Isolation Power Transformer for Industrial Applications
Order the Triad N48X isolation power transformer online today to enhance safety and reliability in your electrical setups. Designed with non-concentrically wound coils and laminate core, it provides 1500V isolation, preventing electrical connection under overload conditions. Rated for 115V input at 50/60Hz, it ensures secure operation in industrial environments. Constructed with Class B insulation materials, it meets RoHS standards. Its robust build and proven safety features make it an ideal choice for professional electrical isolation, protecting sensitive equipment and ensuring compliance with safety regulations.
Get Triad N48X today—built for precise electrical isolation and long-lasting durability in industrial systems.
