TRIAD MAGNETICS VPT122080 Toroidal Power Transformer
This toroidal power transformer reduces stray magnetic fields, offers higher efficiency, and has a smaller size compared to traditional EI transformers. It features a Class B (130°C) insulation system and provides a maximum power of 25 VA. The transformer operates at approximately 87% efficiency at full load. It can be configured for different input voltages: 230VAC in series or 115VAC in parallel. The output includes a 12VAC center-tapped connection at 2.08A and a 6VAC at 4.16A in parallel. It comes with a metal mounting plate, two rubber pads, and mounting hardware including an M5 x 40mm bolt, nut, spring washer, and flat washer.
TRIAD MAGNETICS VPT122080 Toroidal Power Transformer Specifications:
- Maximum Power: 25VA
- Input Voltage: Series: 230VAC, 50/60Hz; Parallel: 115VAC, 50/60Hz
- Output Voltage: Series: 12VAC CT @ 2.08A; Parallel: 6.0VAC @ 4.16A
- Efficiency: 87% TYP at full load
- Insulation System: Class B (130°C)
- Construction: Toroidal design
- Dimensions (mm): Height +3mm for mounting hardware, specific measurements available upon request
- Weight: 0.4kg
- Protection: Safety complies with UL, CE standards
- Mounting: Metal plate, rubber pads, hardware included
- Connections: 8-inch lead wires, primaries 22AWG, secondaries 20AWG
- Standards: UL File E122529, EN standards for safety and EMC
- RoHS compliant as of February 2016
Buy the Buy Triad Power Transformer Part Number VPT122080 Online
Order the Toroidal Power Transformer VPT122080 today and experience reliable, efficient power conversion for your electrical projects. Designed with a toroidal core, it reduces stray magnetic fields and increases efficiency, making it suitable for various industrial and electronic applications. Its versatile input configurations allow seamless integration into different systems, whether in series or parallel. With safety standards met, high-quality mounting hardware included, and RoHS compliance, this transformer guarantees long-lasting performance and easy installation for professional or DIY use.
Buy Triad VPT122080 power transformer now and enhance your electrical system with high efficiency, reliable operation, and easy mounting options.
