TRIAD MAGNETICS VPT361390 Industrial Power Transformer
This transformer offers a 50VA power capacity with primary voltages of 230VAC and 115VAC, and secondary voltages of 36VAC CT and 18VAC in series and parallel configurations. Constructed with toroidal design, it reduces stray fields, enhances efficiency, and minimizes size, ideal for industrial use. It features Class B insulation, safety compliance with UL and CE standards, and a maximum temperature rise of 40°C. Its robust mounting and dual wiring options make it suitable for demanding environments, ensuring reliable performance and compliance with international safety standards.
TRIAD MAGNETICS VPT361390 Industrial Power Transformer Specifications:
- Maximum Power: 50VA
- Input Voltage: Series: 230VAC, 50/60Hz; Parallel: 115VAC, 50/60Hz
- Output Voltage: Series: 36VAC CT @ 1.39A; Parallel: 18.0VAC @ 2.78A
- Voltage Regulation: 12% TYP from full load to no load
- Temperature Rise: 40°C TYP
- Hipot: 4000VAC, Primary to Secondary
- Efficiency: 86% TYP @ full load
- Construction: Toroidal, Class B (130°C) insulation
- Dimensions: Varies, add 3mm to height for mounting hardware
- Weight: 0.6Kg
- Mounting: Metal plate with rubber pads, includes bolts and washers
- Connections: 8-inch, 24 AWG stranded UL 1015 leads, primary: 22AWG, secondary: 20AWG
- RoHS Compliance: Yes, meets 2011/65/EU requirements
Buy the Triad Magnetics VPT36-1390 – Reliable Transformer for Industrial Applications
Purchase the Triad Magnetics VPT36-1390 transformer online today and ensure reliable power supply for your industrial projects. Designed with toroidal construction, it reduces stray fields, improves efficiency, and fits demanding environments. With dual voltage options, robust safety standards, and easy mounting, this 50VA transformer offers dependable performance. Its compact size, international safety compliance, and long-lasting durability make it the ideal choice for professional electrical and industrial applications. Buy now for a proven, high-quality power solution designed to meet your needs.
Get Triad Magnetics VPT36-1390 today—built for demanding industrial environments and long-lasting performance.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS VPT361390?
You can click on the BUY or RFQ button to purchase VPT361390 from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part VPT361390?
You can download the VPT361390 datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of VPT361390?
TRIAD MAGNETICS
