TRIAD MAGNETICS VPT244170 Toroidal Power Transformer
The World Series Triad chassis mount toroidal transformer offers efficient, compact, and cool operation. It is certified to UL 506, CE IEC 61558-1, and IEC 61558-2-6 standards. Constructed with a Class B (130°C) rated insulation system, this transformer features minimal stray magnetic fields for quiet operation around sensitive circuits. It has dual primary and secondary windings, electrically isolated from each other and the core, providing flexibility for various input and output voltage configurations. The transformer includes connection leads, a center tap contact, and a 4000VAC hipot test. Suitable for industrial applications, it delivers up to 100VA, with a typical efficiency of 86% at full load.
TRIAD MAGNETICS VPT244170 Toroidal Power Transformer Specifications:
- Maximum Power: 100VA
- Input Voltage: Series: 230VAC, 50/60Hz; Parallel: 115VAC, 50/60Hz
- Output Voltage: Series: 24VAC CT @ 4.17A; Parallel: 12.0VAC @ 8.34A
- Voltage Regulation: 9% TYP from full to no load
- Temperature Rise: 45°C TYP
- Hipot: 4000VAC, Primary to Secondary
- Efficiency: 86% TYP at full load
- Construction: Toroidal, Class B insulation (130°C)
- Dimensions: Size varies, approximately 105mm x 60mm x 50mm
- Weight: 1.0Kg
- Connections: 8-inch long, 0.25-inch stripped, tinned leads
- RoHS Compliance: Yes
- Safety Certifications: UL 506, CE IEC 61558-1, IEC 61558-2-6
- Isolation: Dual primary and secondary windings, electrically isolated from core
- Additional Features: Center tap, 4000VAC hipot test, RoHS compliant
- Mounting: Metal mounting plate with rubber pads, includes mounting hardware
Buy the Triad Series Toroidal Transformer: VPT24-4170
Enhance your industrial setup with the Toroidal Power Transformer featuring high efficiency, dual windings for versatile voltage configurations, and UL and CE safety certifications. Its compact design ensures minimal stray magnetic fields, ideal for sensitive electronic circuits. Constructed for durability with Class B insulation, it provides reliable operation at up to 100VA, making it perfect for various industrial and control panel applications. Purchase online now to benefit from fast shipping, expert support, and a cost-effective power transformation solution.
Get Triad Series VPT24-4170 today—built for efficiency, safety, and flexible power conversion in industrial applications.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS VPT244170?
You can click on the BUY or RFQ button to purchase VPT244170 from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part VPT244170?
You can download the VPT244170 datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of VPT244170?
TRIAD MAGNETICS
