TRIAD MAGNETICS VPT483300 Industrial Power Transformer
This power transformer features toroidal construction for reduced stray fields, increased efficiency, and compact size. It offers 160VA power capacity, with output voltages of 48VAC CT at 3.33A in series and 24VAC at 6.66A in parallel. Designed with Class B insulation and meeting international safety standards, it ensures reliable operation in industrial environments. The transformer includes a mounting plate, rubber pads, and UL 1015 lead wires. It complies with RoHS regulations and provides efficient, safe power conversion for demanding applications.
TRIAD MAGNETICS VPT483300 Industrial Power Transformer Specifications:
- Maximum Power: 160VA
- Input Voltage: Series 230VAC, 50/60Hz; Parallel 115VAC, 50/60Hz
- Output Voltage: Series 48VAC CT at 3.33A; Parallel 24VAC at 6.66A
- Voltage Regulation: 8% typical from full to no load
- Temperature Rise: 50°C typical
- Hipot: 4000VAC primary to secondary
- Efficiency: 89% typical at full load
- Construction: Toroidal, Class B insulation
- Dimensions: Height +3mm for mounting hardware, weight 1.6kg
- Connections: UL 1015 lead wires, primary 22AWG, secondary 18AWG
- Safety: Meets UL, CE standards, RoHS compliant
- Mounting: Metal plate with rubber pads, includes hardware
Buy the Buy Triad Power Transformer Part Number VPT48-3300 Online
Purchase the Triad VPT48-3300 power transformer online today to ensure reliable power conversion in industrial settings. With toroidal construction for reduced stray fields, this 160VA transformer offers dual outputs of 48VAC CT and 24VAC, ideal for demanding applications. It features UL and CE safety certifications, RoHS compliance, and includes mounting hardware for easy installation. Built with Class B insulation and optimized for efficiency, this transformer is perfect for ensuring safe, long-lasting performance in your industrial projects. Buy now and enhance your power system reliability.
Get Triad VPT48-3300 power transformer today—designed for industrial reliability and efficiency in demanding environments.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS VPT483300?
You can click on the BUY or RFQ button to purchase VPT483300 from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part VPT483300?
You can download the VPT483300 datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of VPT483300?
TRIAD MAGNETICS
