TRIAD MAGNETICS WSU0751500 power supply
This component is designed for power management and industrial applications, providing reliable performance in various electronic systems.
TRIAD MAGNETICS WSU0751500 power supply Specifications:
- Input Voltage Range: 90-264VAC, 50-60Hz
- Input Current: <0.4A RMS at 115VAC
- Max Inrush Current: <60A peak at 115VAC (Cold start)
- Output Voltage: 7.5VDC
- Output Current: 1.54A
- Efficiency: 82.7%
- Ripple & Noise: 150mVpk-pk Max
- Standby Power: <100mW
- Operating Temperature: 0°C to +40°C at full load
- Storage Temperature: -20°C to +60°C
- Humidity: 5% to 95%, Non-condensing
- Leakage Current: <0.25mA at 264VAC
- Dielectric Strength: 4242VDC for 3 seconds
- Safety Certifications: UL, CSA, FCC Class B
- Case Type: Thermoplastic molded enclosure
- Output Cord: 18 AWG, 5 feet long
- RoHS & Level VI Efficiency Compliance
Buy the Triad Series Power Supply: WSU075-1500
Order the Triad power supply WSU075-1500 online today and experience reliable power management for industrial and electronic applications. Designed for efficiency and safety, it ensures consistent performance with features like UL, CSA, and FCC certification. With an output of 7.5VDC at 1.54A, this durable enclosure and RoHS compliance make it an excellent choice for demanding systems. Purchase now for fast delivery and get a trusted power solution for your electronics needs.
Get Triad WSU075-1500 today—built for power management and industrial reliability with high efficiency and safety standards.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS WSU0751500?
You can click on the BUY or RFQ button to purchase WSU0751500 from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part WSU0751500?
You can download the WSU0751500 datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of WSU0751500?
TRIAD MAGNETICS
