TRIAD MAGNETICS WSU1500800R13 Power Supply
The WSU150-0800-R13 from Triad Magnetics is a compact, reliable, and energy-efficient wall plug-in power supply providing a regulated 15V DC output at 0.8A. It supports a wide input voltage range of 100VAC to 240VAC at 50Hz/60Hz, meeting Level VI efficiency standards, and features a thermoplastic molded enclosure for durability and safety. With UL, CSA, and ETL certifications, it is designed for power management and industrial use, offering low noise operation, a 5-foot output cord, and a dielectric strength of 4kVDC for 60 seconds, all within an ambient temperature of 0°C to +40°C.
TRIAD MAGNETICS WSU1500800R13 Power Supply Specifications:
- Input Voltage range: 100-240VAC, 50-60Hz
- Output Voltage: 15VDC
- Output Current: 0.8A
- Max Power: 12W
- Regulation: +5%
- Ripple & Noise: 150mVpk-pk Max
- Efficiency: Level VI, meets minimum standards
- Operating Temperature: 0°C to +40°C
- Storage Temperature: -20°C to 60°C
- Humidity: 5% to 95%
- Dielectric Strength: 4242VDC for 3 seconds
- Output Cord: 24 AWG, 6 Ft. long
- Enclosure: Thermoplastic molded case
- Safety Certifications: UL, CSA, ETL
- Leakage Current: <0.25mA
- Over voltage & short circuit protection: Yes
- RoHS compliant: Yes
Buy the Triad Series Power Supply: WSU150-0800-R13
Upgrade your power management with the Triad WSU150-0800-R13 power supply. This compact, efficient device offers a regulated 15V DC output at 0.8A, supporting wide input voltage and complying with Level VI energy standards. Its durable thermoplastic case ensures safety and durability, making it ideal for industrial, commercial, and electronic projects. With UL, CSA, and ETL certifications, it guarantees reliable performance, low noise, and protection features. Enhance your systems today with this versatile, certification-approved power solution for optimal operation and longevity.
Order your Triad Power Supply WSU150-0800-R13 today and ensure your projects enjoy dependable, efficient power with certified safety and low noise operation.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS WSU1500800R13?
You can click on the BUY or RFQ button to purchase WSU1500800R13 from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part WSU1500800R13?
You can download the WSU1500800R13 datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of WSU1500800R13?
TRIAD MAGNETICS
