TRIAD MAGNETICS WSU150240013 Industrial Power Supply
The WSU150-2400-13 from Triad Magnetics is a compact, versatile switch mode power supply designed for safe and efficient operation. It supports an input voltage range of 100VAC to 240VAC at 50Hz/60Hz and delivers a stable 15VDC output with a maximum current of 2.4A, providing up to 36W of power. The device features a thermoplastic molded enclosure, measures approximately 2.5mm (ID) x 5.5mm (OD) x 11mm (L) for the output plug, and includes an 18 AWG, 6-foot output cord. It complies with UL, CSA, and EMI standards, with robust dielectric strength, and operates safely in temperatures from 0°C to 40°C, making it ideal for industrial and power management applications.
TRIAD MAGNETICS WSU150240013 Industrial Power Supply Specifications:
- Input Voltage range: 100-240VAC, 50-60Hz
- Input current: <1.3A(RMS) @ 115VAC
- Max Inrush Current: <60A peak @ 115VAC
- Output Voltage: 15VDC
- Output Current: 2.4A
- Power: 36W maximum
- Regulation: +5%
- Ripple & Noise: 150mVpk-pk Max
- Efficiency: Meets Level VI standards
- Operating Temperature Range: 0°C to +40°C
- Storage Temperature Range: -20°C to 60°C
- Humidity: 5% to 95%, Non-condensing
- Dielectric Strength: 4242VDC for 60 seconds
- Certifications: UL, CSA, FCC Part 15 Class B
- Enclosure: Thermoplastic molded
- Output Cord: 18 AWG, 6 feet long
- Over voltage and short circuit protection
- RoHS compliant
Buy the Triad Power Supply WSU150-2400-13 – Reliable Power for Industrial Applications
Purchase the Triad Power Supply WSU150-2400-13 online today for reliable power delivery in industrial environments. Featuring wide input voltage support from 100VAC to 240VAC, it produces a stable 15VDC, 2.4A output with 36W capacity. Designed with a thermoplastic enclosure, it is UL and CSA certified, ensuring safety and efficiency. Its compact size, low noise, and versatile compatibility make it ideal for power management in industrial automation, security, and control systems. Order now for quick, safe, and reliable power solutions.
Get Triad Power Supply WSU150-2400-13 today—built for durability, safety, and versatile industrial use.
