TRIAD MAGNETICS WSU2400500R13 Industrial Power Supply
The WSU240-0500-R13 from Triad Magnetics is a compact, thermoplastic-moulded wall plug-in switch mode power supply engineered for versatile, reliable power delivery. It accepts an input voltage range of 100VAC to 240VAC at 50Hz/60Hz, delivering a regulated 24VDC with up to 0.5A current. Its enclosed design reduces noise and size, eliminating internal cooling fans and enhancing safety. Equipped with a 2.5mm inner diameter and 5.5mm outer diameter output plug, plus a 5-foot 24AWG cord, it complies with UL 60950-1 and CSA standards, supporting industrial and power management applications with high dielectric strength and efficiency.
TRIAD MAGNETICS WSU2400500R13 Industrial Power Supply Specifications:
- Input Voltage Range: 100-240VAC, 50-60Hz
- Output Voltage: 24VDC
- Output Current: 0.5A
- Ripple & Noise: 200mVpk-pk Max
- Efficiency: Meets Level VI standards
- Dimensions: Compact thermoplastic case, output plug 2.5mm inner, 5.5mm outer diameter
- Output Cord: 24 AWG, 6 ft long
- Operating Temperature: 0°C to +40°C
- Storage Temperature: -20°C to 60°C
- Dielectric Strength: 4KVDC for 60 seconds
- Safety Standards: UL 60950-1, CSA, FCC Part 15 Class B, Double Insulated
- RoHS Compliant: Yes
- Certifications: ETL, tested for safety and EMI compliance
- Reliability: 5-year warranty
- Leakage Current: <0.25mA at 264VAC
Buy the Triad Series Power Supply: WSU240-0500-R13
Secure your industrial power solutions by purchasing the Triad WSU240-0500-R13 online today. This reliable, compact switch mode power supply offers a wide input voltage range from 100VAC to 240VAC, delivering a stable 24VDC at 0.5A current for various applications. Its enclosed thermoplastic design minimizes noise and size, ensuring safe operation with high dielectric strength and compliance with UL, CSA, and RoHS standards. Perfect for power management and industrial uses, it features a long 6-foot output cord with a 2.5mm inner diameter and 5.5mm outer diameter plug, providing efficient, safe, and dependable power delivery.
Buy Triad WSU240-0500-R13 now and experience unmatched reliability and high efficiency for industrial power management needs.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS WSU2400500R13?
You can click on the BUY or RFQ button to purchase WSU2400500R13 from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part WSU2400500R13?
You can download the WSU2400500R13 datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of WSU2400500R13?
TRIAD MAGNETICS
