TTElectronics - Welwyn GWCR060333RFT5 Thick-Film Resistor
Green Thick-Film Chip Resistors from the GWCR Series offer RoHS compliance and are lead-free, suitable for surface mounting in electronic circuits. Available in sizes from 01005 to 2512, these resistors feature a high alumina substrate with ruthenium oxide resistance elements, silver palladium, nickel, and tin-plated terminations. They provide stable resistance values from 1R to 10M ohms, withstand voltages up to 250V, and operate in temperatures from -55°C to +155°C. Resistance tolerances are ±1%, with excellent solvent resistance and board flex capabilities, making them ideal for high-reliability electronics applications.
TTElectronics - Welwyn GWCR060333RFT5 Thick-Film Resistor Specifications:
- Size range: 01005 to 2512
- Resistance range: 1R to 10M ohms
- Power rating @ 70°C: 0.031W to 1W
- Limiting element voltage: up to 250V
- Resistance tolerance: ±1%
- Temperature range: -55°C to +155°C
- Dielectric withstand volts: up to 500V
- Termination material: Silver palladium, nickel, tin-plated
- Physical dimensions vary by size, e.g., 0603 approx. 1.6mm x 0.8mm
- Alumina substrate: 96% minimum
- Marking: EIA-96 codes for sizes 0603 and below
- Protection: Glazed coating resistant to industrial cleaning fluids
- Construction: Ruthenium oxide resistance element on alumina substrate
- Compliance: RoHS, EU Directive 2011/65/EU
Buy the Buy TT Electronics GWCR Series Resistors Part Number GWCR060333RFT5 Online
Purchase the TT Electronics GWCR series thick-film resistor online today to benefit from reliable, RoHS-compliant surface-mount resistors that deliver consistent performance across a wide temperature range. These lead-free resistors suit high-reliability applications requiring resistance values from 1R to 10M ohms and voltages up to 250V. Available in sizes from 01005 to 2512, they feature high alumina substrates with ruthenium oxide resistance elements, ensuring durability and stability. Order now for fast delivery and guaranteed manufacturer quality.
Order your TT Electronics GWCR060333RFT5 thick-film resistor today and ensure high stability and RoHS compliance for your electronic projects.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn GWCR060333RFT5?
You can click on the BUY or RFQ button to purchase GWCR060333RFT5 from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part GWCR060333RFT5?
You can download the GWCR060333RFT5 datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of GWCR060333RFT5?
TTElectronics - Welwyn
