TTElectronics - Welwyn GWCR08054K7FT5 Thick-Film Chip Resistor
The Green Thick-Film Chip Resistors from the GWCR Series are high-quality, RoHS-compliant components designed for precise resistance in compact sizes from 01005 to 2512. Featuring alumina substrates and ruthenium oxide elements, these resistors offer excellent stability, low temperature coefficients, and resistance values from 1Ω to 10MΩ. They are suitable for industrial applications requiring high reliability, with good solderability, resistance to cleaning fluids, and packaging optimized for automated assembly. Their robust construction ensures durability in diverse electronic environments, making them ideal for demanding circuit designs.
TTElectronics - Welwyn GWCR08054K7FT5 Thick-Film Chip Resistor Specifications:
- Sizes: 01005, 0201, 0603, 0805, 1206, 1210, 1812, 2010, 2512
- Resistance range: 1Ω to 10MΩ
- Power rating @ 70°C: 0.031W (01005) to 1W (2512)
- Limiting element voltage: 15V to 250V
- Resistance tolerance: ±1%
- Resistance stability: ±400 ppm/°C (values up to 10Ω), ±200 ppm/°C (values 10Ω-100Ω), ±100 ppm/°C (>100Ω)
- Ambient temperature range: -55°C to +155°C
- Dielectric withstand voltage: 100V to 500V
- Insulation resistance: 2160Ω
- Terminations: Silver palladium, nickel, tin plated; meet IEC standards
- Physical dimensions vary with size: Lengths from approximately 0.40mm to 4.00mm, widths from 0.15mm to 4.0mm, weights from mg range
- Construction: Alumina substrate (96% min), ruthenium oxide resistor element, glazed protective coat
- Marking: Individual marking with significant figures, 'R' for decimal points, zero ohm jumpers marked 'O'
- Packaging: 8mm or 12mm reels, sizes in tape for automated assembly
Buy the TT Electronics GWCR08054K7FT5 – Reliable Thick-Film Chip Resistor for Industrial Applications
Discover the high-performance thick-film chip resistor from TT Electronics. The GWCR Series offers accurate resistance, robust construction, RoHS compliance, and a range of sizes suitable for industrial and electronic applications. Perfect for demanding environments, these resistors feature excellent stability, low temperature coefficients, and reliable solderability. Packaged for automated assembly, they resist cleaning fluids and meet IEC standards for durability. Order online now to enhance circuit reliability with these proven, long-lasting, and environmentally friendly resistors designed for precision electronic systems.
Get TT Electronics GWCR08054K7FT5 today—built for precision and long-lasting durability in demanding circuits.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn GWCR08054K7FT5?
You can click on the BUY or RFQ button to purchase GWCR08054K7FT5 from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part GWCR08054K7FT5?
You can download the GWCR08054K7FT5 datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of GWCR08054K7FT5?
TTElectronics - Welwyn
