TTElectronics - Welwyn LRMAM1206R022FT5 Low Resistance Resistor
The LRMAM1206R022FT5 is a low resistance metal alloy resistor designed for precise current sensing in power electronics. It features a resistance value of 22 milliohms with a ±5% tolerance, and is suitable for high-temperature operation up to 170°C. This resistor is RoHS compliant, halogen free, and compatible with multiple reflow soldering profiles, making it ideal for industrial, automotive, and electronic applications requiring accurate low-resistance measurements and reliable performance under thermal stress.
TTElectronics - Welwyn LRMAM1206R022FT5 Low Resistance Resistor Specifications:
- Resistance Range: 0.5mΩ to 500mΩ
- Power Rating @70°C: 0.2W (0805), 1W (1206), 2W (2512)
- Resistance Tolerance: ±0.5%, ±1%, ±5%
- Temperature Coefficient (25°C to 125°C): +100 ppm/°C to -50 ppm/°C
- Maximum Operating Temperature: 170°C
- Insulation Resistance: >100 MΩ
- Element Material: Mn-Cu, Cu-Ni alloy
- Physical Dimensions (mm): Size 1206 - Length 3.2, Width 1.6, Height 0.8
- Marking: Ohmic value, e.g., 'R022' for 22mΩ
- Soldering Profile: Pre-heat at 150-180°C for 60-120s, reflow at 230°C for 20-40s, peak at 255-260°C for 5s
Buy the Buy TT Electronics Low Resistance Metal Alloy Resistor Part Number LRMAM1206R022FT5 Online
Purchase the TT Electronics Low Resistance Metal Alloy Resistor LRMAM1206R022FT5 online today to ensure high accuracy in current sensing applications. This resistor offers a resistance value of 22mΩ with a ±5% tolerance, designed for high-temperature environments up to 170°C. Its RoHS compliance and halogen-free construction make it suitable for various industrial and automotive electronics. With optimal physical dimensions and soldering profile recommendations, it guarantees reliable performance and durability in demanding operational conditions, ensuring your electronic circuits perform flawlessly and efficiently.
Order your TT Electronics Series1206 Low Resistance Metal Alloy Resistor LRMAM1206R022FT5 today and equip your projects with precision current sensing components.
