TTElectronics - Welwyn WCR080522KFI General Purpose Surface Resistors
The WCR series resistors are general-purpose, surface-mounted components designed for reliable electrical performance in various applications. They feature a high alumina substrate with a ruthenium oxide resistance element, protected by a glazed coating. The resistors offer wide size and ohmic value options, wrap-around terminations, and are RoHS compliant. They withstand ambient temperatures from -55°C to 155°C, with excellent stability, low tolerance, and resistance to industrial cleaning fluids. Suitable for both high and low resistance values, they ensure durability and consistent operation in electronic circuits.
TTElectronics - Welwyn WCR080522KFI General Purpose Surface Resistors Specifications:
- Resistance Range: from less than 1Ω to 10MΩ
- Resistance Tolerance: ±1%, ±2%, ±15%, ±20%, ±30%
- Temperature Coefficient: -400 to +600ppm/°C for low values, +200 to +300ppm/°C for high values
- Ambient Temperature Range: -55°C to 155°C
- Construction: High alumina substrate (96% min), ruthenium oxide resistive element, glazed protection
- Terminations: Wrap-around, solderable, meet IEC 115-1 requirements
- Load Life Stability: ±2% after 1000 hours at 70°C
- Shelf Life: 12 months at room temperature
- Voltage Proof: 25V to 500V depending on resistance value
- Packaging: Tape mounted on reels, 8mm, 12mm, or 12mm plastic tape as per IEC standards
Buy the TT Electronics Series WCR Resistors: WCR080522KFI
Buy TT Electronics Series WCR resistors online today and benefit from high reliability, wide resistance ranges, RoHS compliance, and excellent stability. These surface-mounted resistors are suitable for a variety of electronic applications, offering wrap-around terminations, robust construction, and proven durability. Whether for high or low Ohmic values, order now to ensure your projects meet industry standards with quality components designed for long-term performance and stability under demanding conditions. Fast shipping and easy online ordering available.
Order your TT Electronics Series WCR resistors today and ensure dependable performance for your electronic projects with high reliability and wide value options.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn WCR080522KFI?
You can click on the BUY or RFQ button to purchase WCR080522KFI from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part WCR080522KFI?
You can download the WCR080522KFI datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of WCR080522KFI?
TTElectronics - Welwyn
