TTElectronics - Welwyn WSMHP201R0J High Power Surface Mount Resistor
The surface mount high power resistors from the WSMHP Series are designed for high-density PCB installation with low thermal resistance and non-inductive construction. They are rated for 20, 25, and 35 watts with a TO-263 package, suitable for board mounting via solder or clip. These AEC-Q200 qualified resistors feature a broad resistance range from 0.1Ω to 100KΩ, operate within -55°C to +175°C, and have a dielectric strength of 2000V DC for 60s. Their compact design ensures high reliability in demanding industrial applications.
TTElectronics - Welwyn WSMHP201R0J High Power Surface Mount Resistor Specifications:
- Power rating: 20W, 25W, 35W
- Package: TO-263 surface mount
- Resistance range: 0.1Ω to 100KΩ
- Operating temperature: -55°C to +175°C
- Dielectric strength: 2000V DC for 60s
- Thermal resistance: 33°C/W (with heatsink), unspecified without heatsink
- Voltage: 500V de or ac rms (limiting element voltage)
- Resistance tolerances: ±5%, ±1%, ±0.5%
- TCR: <3 ppm/°C, varies by resistance
- Dimensions: Length approximately 10.1 mm, width 4.6 mm (varies by model)
- Insulation resistance: >10GΩ
- Body material: RoHS compliant, Pb-free
- Suitable for high temperature, vibration, humidity, and soldering heat testing
Buy the TT Electronics WSMHP201R0J – Reliable High Power Resistor for Industrial Applications
Purchase the high power surface mount resistor WSMHP201R0J online today. Designed for high-density PCB applications, it offers low thermal resistance, broad resistance options, and high reliability. Suitable for demanding industrial environments, these resistors are compliant with RoHS standards, provide excellent dielectric strength, and operate across a wide temperature range. Their compact TO-263 package makes installation straightforward, ensuring your projects benefit from dependable performance and enhanced thermal management. Buy now to upgrade your industrial circuitry with proven high power resistors.
Order your TT Electronics Series WSMHP201R0J high power resistor today and ensure reliable performance in demanding industrial circuits.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn WSMHP201R0J?
You can click on the BUY or RFQ button to purchase WSMHP201R0J from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part WSMHP201R0J?
You can download the WSMHP201R0J datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of WSMHP201R0J?
TTElectronics - Welwyn
