Telemecanique Sensors XT230A1FBL2 Capacitive Proximity Sensor
The capacitive proximity sensor features a cylindrical M30 design with a plastic body, rated IP67 for durable protection, and operates on 24 to 240 V AC. It detects insulated or conductive materials with a sensing distance up to 11 mm (0.43 in) and an adjustable face zone up to 17 mm (0.67 in). Suitable for fixed body mounting, it offers discrete NC output, a response delay under 30 ms, and features IP67 double insulation, CE marking, and sensitivity adjustment via potentiometer. Its application spans industrial sensing and automation for accurate, reliable proximity detection.
Telemecanique Sensors XT230A1FBL2 Capacitive Proximity Sensor Specifications:
- Sensor type: Capacitive proximity sensor
- Body design: Cylindrical M30
- Material: Plastic
- Enclosure rating: IP67, double insulation
- Detection face: Frontal
- Nominal sensing distance: 15 mm (0.59 in)
- Adjustment zone: 0-17 mm (0-0.67 in)
- Output: Discrete NC, 2-wire AC circuit
- Supply voltage: 24-240 V AC, 50/60 Hz, range 20-265 V AC
- Maximum delay: 30 ms
- Response delay first up: 200 ms
- Switching frequency: ≤ 25 Hz
- Maximum switching current: 300 mA
- Voltage drop: <10 V (closed)
- Current consumption: <4 mA
- Wiring: Cable 2 m (6.56 ft), PVC insulated
- Dimensions: Length 74.5 mm (2.93 in), threaded length 48.5 mm (1.91 in)
- Mounting: Fixed body, face to face or side by side with minimum distances
- Vibration resistance: 10 gn, 1 mm, 10-55 Hz
- Shock resistance: 30 gn, 11 ms
- Operating temperature: -10°C to 60°C (4°F to 140°F)
- Certifications: CE, CULus
- Compliance: EN/IEC 60947-5-2
- Environmental resistance: Electrostatic, electromagnetic, fast transient resilience
Buy the Schneider Electric XT230A1FBL2 – Reliable Capacitive Proximity Sensor for Industrial Applications
Enhance your automation setup with the Schneider Electric capacitive proximity sensor, featuring a cylindrical M30 design, IP67 rating, and adjustable detection zone. Operating on 24 to 240 V AC, it offers highly reliable detection within an 11 mm sensing distance, suitable for insulated or conductive materials. Its discrete NC output, quick response, and robust construction make it ideal for industrial environments. Buy online today to ensure precise, durable, and versatile proximity detection in your automation projects, backed by an 18-month warranty for peace of mind.
Buy Schneider Electric XT230A1FBL2 now and experience unmatched reliability and performance in industrial proximity sensing with adjustable zones and IP67 protection.
