Vishay 11A41B10 Datasheet & Stock

The 11A41B10 is a 25.4mm Dial made of satin chrome finish with white markings. It has 6.35mm shaft diameter and it is suitable for use with precision potentiometers or other rotating devices. The indication is single counter type wheel and a graduated circular dial registering a total count of 11-turn. The single numeral in window (0 thru 10) indicates completed number of turns of the drive sleeve. The graduated circular dial indicates the percent of the partial turn of the drive sleeve. The accuracy is zero backlash between graduated dial and the drive sleeve.




Round vernier scale

Between 97 and 0 transfer point

Accuracy - zero backlash between dial and the drive sleeve

Rotation increasing indication - CW direction

Rotation decreasing indication - CCW direction





Applications


Industrial





Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
