Vishay BFC233820105 Interference Suppression Capacitor
These are interference suppression film capacitors designed for across-the-line X2 applications, made with polypropylene dielectric and metallized film electrodes. They are encapsulated in flame-retardant, epoxy resin sealed plastic cases, comply with UL 94 V-0, and feature rated voltages up to 310 Vac with permissible DC voltages of 630 V. Suitable for use in power line interference filtering, RF suppression, and electronic noise reduction, they come in various pitches including 7.5 mm, 10 mm, 15 mm, 22.5 mm, and 27.5 mm, with different dimensions and lead length options to fit specific PCB mounting requirements.
Vishay BFC233820105 Interference Suppression Capacitor Specifications:
- Capacitance range: 0.001 pF to 3.3 µF (preferred values according to E12 series)
- Capacitance tolerance: ±20%, +10%, 25%
- Rated AC voltage: 310 Vac at 50/60 Hz
- Permissible DC voltage: 800 V at 85°C, 630 V at 110°C
- Max application temperature: 110°C (for C<470 nF, 125°C for less than 1000h), 110°C for C>470 nF
- Dielectric: Polypropylene film
- Electrodes: Metallized film
- Encapsulation: Flame-retardant epoxy resin sealed plastic case
- Lead pitch options: 7.5 mm, 10 mm, 15 mm, 22.5 mm, 27.5 mm
- Lead lengths vary: short (3.5+0.5 mm), long (up to 25 mm)
- UL class 94 V-0 flammability rated
- Compliance: RoHS, UL, CSA, CQC standards
- Impulses withstand voltage up to 2.5 kV (full wave peaks), endurance 1000 hours at 1.25× rated voltage
Buy the Buy Vishay MKP338 2 X2 Part Number 338 2X Online
Order Vishay MKP338 2 X2 film capacitor online to ensure optimal noise filtering and power line interference suppression. These polypropylene dielectric capacitors are flame retardant, UL approved, and come in multiple pitches and dimensions suited for PCB mounting. They reliably handle voltages up to 310 Vac and feature high endurance for long-term performance in industrial and electronic applications. Purchase now to benefit from fast delivery and certified quality, ideal for power line noise reduction and RF interference filtering.
Get Vishay MKP338 2 X2 today—designed for interference suppression with high current ratings and long-lasting reliability.
Frequently Asked Questions
Where can I buy Vishay BFC233820105?
You can click on the BUY or RFQ button to purchase BFC233820105 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part BFC233820105?
You can download the BFC233820105 datasheet or visit the Vishay website for support.
Who is the manufacturer of BFC233820105?
Vishay
