Vishay BFC233840475 Interference Suppression Capacitor
The Vishay MKP338 4 X2 is a high-quality interference suppression film capacitor designed for across-the-line X2 applications. It features polypropylene film dielectric, metallized film electrodes, and a flame-retardant epoxy sealed plastic case. Rated for 300 Vac and 105°C, it offers excellent self-healing properties, low tangents of loss angle at various frequencies, and robust performance under vibration, shock, and environmental conditions. Suitable for electromagnetic interference filtering in industrial and electronic equipment, it ensures reliability and safety compliance with international standards like IEC 60384-14 and UL 60384-14.
Vishay BFC233840475 Interference Suppression Capacitor Specifications:
- Capacitance range: 0.01 UF to 10 UF (preferred values according to E6)
- Rated voltage: 300 Vac at 50/60 Hz, 800 Vpc at 85°C, 630 Vdc at 110°C
- Temperature rating: 105°C; Max application temperature: 105°C
- Dielectric: Polypropylene film; Electrodes: Metallized film; Construction: Mono
- Encapsulation: Plastic case, epoxy resin sealed, flame-retardant UL-class 94 V-0
- Lead pitches: 15 mm to 55 mm with different options; Lead lengths: 3.5 mm, 5.0 mm, 25.0 mm
- Dimensions vary with pitch size; Wave soldering: 280°C for 10s; Compliance: IEC 60384-14, UL 60384-14, ENEC
- Permissible AC and pulse voltage: 2200 V for 1 min; Insulation resistance: >50 MΩ; Climatic class: 55/105/56
- Self-healing, RoHS compliant, RoHS
- Application: EMI filtering, across-the-line interference suppression, industrial electronics
Buy the VISHAY Series MKP338 Interference Suppression Capacitor Part Number BFC233840475
Secure your EMI filtering needs with the Vishay MKP338 4 X2 interference suppression capacitor. Rated for 300 Vac and 105°C, it features polypropylene dielectric and robust flame-retardant encapsulation. Designed for across-the-line applications, it offers excellent self-healing properties, low loss angle at various frequencies, and compliance with international safety standards. Easy to mount with multiple lead pitch options and proven durability under vibration, shock, and environmental stresses. Perfect for industrial, consumer, and electronic equipment requiring effective interference suppression and long-term reliability.
Order your Vishay MKP338 4 X2 interference suppression capacitor today and ensure reliable EMI filtering in your electronic and industrial projects.
Frequently Asked Questions
Where can I buy Vishay BFC233840475?
You can click on the BUY or RFQ button to purchase BFC233840475 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part BFC233840475?
You can download the BFC233840475 datasheet or visit the Vishay website for support.
Who is the manufacturer of BFC233840475?
Vishay
