Vishay BFC233841104 interference suppression capacitor
The MKP338 4 X2 interference suppression film capacitor is designed for across the line applications with a rated voltage of 300 Vac and a temperature rating of 105°C. It features self-healing properties, a plastic flame-retardant epoxy resin sealed case, and tinned leads for easy mounting on printed-circuit boards. Suitable for EMC filtering in industrial environments, it offers a capacitance range from 0.01 UF to 10 UF with tolerance levels of +20% and +10%. Compliant with IEC 60384-14 standards, it ensures reliable performance under various climatic and electrical stress conditions.
Vishay BFC233841104 interference suppression capacitor Specifications:
- Capacitance range: 0.01 UF to 10 UF
- Rated AC voltage: 300 Vac; 50/60 Hz
- Permissible DC voltage: 800 Vpc at 85°C, 630 Vdc at 110°C
- Temperature rating: 105°C, maximum application temperature
- Dielectric: Polypropylene film, metallized electrodes
- Construction: Mono, plastic case with epoxy resin sealing; flame retardant UL 94 V-0
- Leads: Tinned wire, standard lead pitch 15 mm to 55 mm, various lengths
- Climatic testing: IEC 60068-1, classes 55/105/56/B or C depending on volume
- Compliance: IEC 60384-14, EN60384-14, UL 60384-14, CSA-E384-14, CB-certification
- Physical size options: Pitch sizes from 15 mm up to 55 mm, various dimensions with short or long leads
Buy the Vishay BFC233841104 – Reliable EMC Filter Capacitor for Industrial Applications
Enhance your electrical shielding and noise suppression with the Vishay BFC233841104 interference suppression capacitor. Rated at 300 Vac and 105°C, this RoHS-compliant component provides reliable EMI filtering across a wide capacitance range from 0.01 UF to 10 UF. Its robust construction, flame-retardant case, and compatible lead pitches make it ideal for industrial and IEC-compliant applications. Easily mount on printed-circuit boards with various sizes to suit your design needs. Order online to benefit from quick delivery and assured quality for your electronic filtering requirements.
Order your Vishay Series BFC233841104 interference suppression capacitor today and ensure dependable EMI filtering for your industrial projects.
Frequently Asked Questions
Where can I buy Vishay BFC233841104?
You can click on the BUY or RFQ button to purchase BFC233841104 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part BFC233841104?
You can download the BFC233841104 datasheet or visit the Vishay website for support.
Who is the manufacturer of BFC233841104?
Vishay
