Vishay S470K25SL0N63L6R Ceramic Capacitor
The Vishay S Series ceramic disc capacitors are high-voltage, general-purpose components suitable for temperature compensation, coupling, decoupling, and bypassing applications. Available in Class 1, Class 2, and Class 3 dielectric types, these capacitors offer high capacitance in a small size with high stability and compliance for RoHS standards. They feature silver-plated ceramic discs with tinned copper leads, supplied with straight or kinked leads, epoxy resin coating, and are designed for reliable performance under various environmental conditions.
Vishay S470K25SL0N63L6R Ceramic Capacitor Specifications:
- Capacitance Range: 10 pF to 33,000 pF (various dielectric types)
- Rated Voltage: 1000 Vp, 2000 Vp, 3000 V, 6000 V
- Dielectric Types: Class 1 (SLO, S3N), Class 2 (X7R, Y5P, X5F, Z5U, Y5V), Class 3 (Y5V)
- Tolerance: ±5% (J), ±10% (K), ±20% (M, Z)
- Temperature Range: -55°C to +125°C (Class 1, Class 2), -30°C to +125°C (Class 3)
- Dimensions: Diameter varies from 6.5 mm to 19.0 mm, Thickness from 4.0 mm to 5.5 mm
- Lead Diameter: 0.6 mm ±0.05 mm
- Lead Spacing: 5.0 mm, 6.4 mm, 7.5 mm, 10.0 mm, 12.5 mm
- Operating Life: Designed for reliable operation over extended periods
- Coating: Epoxy resin (UL 94 V-0)
- Mounting Style: Radial leads, straight or kinked
- Compliance: RoHS compliant, temperature stability, and high-voltage capability
Buy the Vishay Series S Ceramic Capacitors: S470K25SL0N63L6R
Purchase the Vishay Series S ceramic capacitor online today to incorporate high-voltage stability and precise capacitance in your electronic applications. These small but robust capacitors are ideal for temperature compensation, coupling, decoupling, and bypassing. They feature high-quality ceramic dielectric materials like SLO, X7R, Y5P, and Y5V, with tolerances as tight as ±5%, and rated voltages up to 6000 V. Available in various sizes with straight or kinked leads, they guarantee reliable operation, easy mounting, and compliance with RoHS standards—making them the perfect choice for technical professionals seeking durability and performance.
Order your Vishay Series S ceramic capacitor today and ensure your electronic projects benefit from high stability, compact design, and reliable performance.
Frequently Asked Questions
Where can I buy Vishay S470K25SL0N63L6R?
You can click on the BUY or RFQ button to purchase S470K25SL0N63L6R from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part S470K25SL0N63L6R?
You can download the S470K25SL0N63L6R datasheet or visit the Vishay website for support.
Who is the manufacturer of S470K25SL0N63L6R?
Vishay
