Vishay BFC233868101 Interference Suppression Capacitor
The Vishay MKP338 series is a class Y2 radial film capacitor specifically engineered for interference suppression in a variety of applications. These capacitors are characterized by their robust construction, AEC-Q200 qualification ensuring suitability for automotive environments, and a design optimized for line-to-ground bypass applications. The capacitor's polypropylene dielectric film construction provides excellent electrical properties, while the epoxy resin encapsulation and flame retardant UL 94 V-0 rating enhance safety and reliability. Typical applications include standard line bypass and continuous operation line bypass in power circuits. Refer to Vishay's application note 28153 for detailed guidance on optimal usage.
Vishay BFC233868101 Interference Suppression Capacitor Specifications:
- Capacitance range: 0.001 μF to 0.47 μF
- Capacitance tolerance: ± 20 %, ± 10 %, ± 5 %
- Rated AC voltage: 300 VAC; 50 Hz to 60 Hz
- Permissible DC voltage: 1000 VDC
- Climatic testing class: 55/105/56/C or 55/105/56/B
- Maximum application temperature: 105 °C
- Reference standards: IEC 60384-14, EN 60384-14, IEC 60065, UL 60384-14
- Dielectric: Polypropylene film
- Electrodes: Metallized film
- Construction: Series construction or Triple construction
- Encapsulation: Plastic case, epoxyresin sealed, flame retardant class UL 94 V-0
- Leads: Tinned wire
- Marking: C-value; tolerance; rated voltage; sub-class; manufacturer’s type designation; code for dielectric material
Buy the BFC233868101 VISHAY Interference Suppression Capacitor | myMectronic
Purchase the Vishay BFC233868101 Interference Suppression Film Capacitor securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy Vishay BFC233868101?
You can click on the BUY or RFQ button to purchase BFC233868101 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part BFC233868101?
You can download the BFC233868101 datasheet or visit the Vishay website for support.
Who is the manufacturer of BFC233868101?
Vishay
