Vishay BFC238330123 Interference Suppression Capacitor
The MKP336 6 Y2 is a high-quality interference suppression film capacitor designed for line and ground applications. With a rated voltage of 300 Vac and a permissible DC voltage of 1000 V, it features a polypropylene dielectric and metallized film electrodes for reliability. Suitable for use in EMI filtering and interference suppression, it complies with RoHS standards, has a fire-retardant epoxy resin sealed plastic case, and is mounted on printed circuit boards either via automatic insertion or manual assembly. Its compact size and robust construction make it ideal for high-frequency and AC line filtering applications, ensuring stability under thermal and electrical stress.
Vishay BFC238330123 Interference Suppression Capacitor Specifications:
- Rated AC Voltage: 300 Vac at 50/60 Hz
- Permissible DC Voltage: 1000 Vdc
- Maximum Application Temperature: 105°C
- Dielectric Material: Polypropylene film
- Electrode Material: Metallized film
- Construction: Series and triple construction for standard pitches
- Dimensions: Pitch 6 mm, lead length 3.5 mm ± 0.5 mm (for pitch = 10 mm), 25 mm ± 2 mm (for pitch = 15 mm)
- Encapsulation: Plastic case, epoxy resin sealed, UL 94 V-0 flame retardant
- Lead Type: Tinned wire
- Flammability: UL 94 V-0
- Climatic Testing: EN 60068-1 class 35/105/56/8
- Standards: IEC 60384-14 ed-4, EN132400, UL 60384-14, CSA-E384-14, CB testing
Buy the Vishay Series MKP336 Interference Suppression Capacitor: BFC238330123
Order the Vishay MKP336 6 Y2 interference suppression capacitor online today. Designed for EMI filtering and line-ground suppression with a 300 Vac rating, it features a durable polypropylene dielectric and metallized film electrodes. Compact and reliable, this capacitor meets RoHS standards, is epoxy resin sealed for safety and durability, and ideal for automated PCB assembly. Whether used in high-frequency filtering or suppression in power supplies, its robust construction ensures long-term stability under thermal and electrical stress, making it perfect for your electronic projects.
Get Vishay MKP336 6 Y2 today—built for interference suppression and reliable line-ground filtering in electrical and electronic circuits.
Frequently Asked Questions
Where can I buy Vishay BFC238330123?
You can click on the BUY or RFQ button to purchase BFC238330123 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part BFC238330123?
You can download the BFC238330123 datasheet or visit the Vishay website for support.
Who is the manufacturer of BFC238330123?
Vishay
