Vishay BFC246840104 EMI Suppression Capacitor
The BFC246840104 is a high-quality interference suppression film capacitor designed for Y2 electromagnetic interference filtering applications. It features a polypropylene dielectric with metallized film electrodes, ensuring stable performance and reliability at rated voltages up to 300 Vac and temperatures up to 105°C. Suitable for mounting on printed circuit boards, it supports automatic insertion and withstands vibration and shock with robust termination resistance. Its epoxy-sealed plastic case meets flame retardant UL 94 V-0 standards, making it ideal for EMI suppression between line and ground in industrial environments.
Vishay BFC246840104 EMI Suppression Capacitor Specifications:
- Rated AC Voltage: 300 Vac 50/60 Hz
- Permissible DC Voltage: 1000 Vdc
- Maximum Application Temperature: 105°C
- Dielectric: Polypropylene film
- Electrodes: Metallized film
- Case Material: Epoxy resin sealed, flame retardant UL 94 V-0
- Lead Pitch: 10 mm to 15 mm
- Lead Length: 3.5 mm ± 0.3 mm (standard), 25 mm ± 2 mm (optional)
- Capacitance Range: 0.001 μF to 0.047 μF (preferred values according to E6 series)
- Capacitance Tolerance: ±20%, +10%
- Climatic Test: EN 60068-1 35/105/56/8
- Mounting: Suitable for automatic insertion in printed circuit boards
- Vibration Resistance: No visible damage under specified conditions
- Shock Resistance: No visible damage after pulse testing
- Flammability: UL 94 V-0 rated epoxy sealed case
- RoHS Compliant: Yes
- Standards: IEC 60384-14 ed-4, EN132400, UL 60384-14
- Dimensions: Lead pitch varies with model, typical height 18.5 mm, length and width depend on capacitance value
- Construction: Series and triple constructions for different lead pitches
- Humidity: Storage at -25°C to +35°C, max 75% RH
Buy the Vishay BFC246840104 – Reliable EMI Suppression Capacitor for Industrial Applications
Order the Vishay BFC246840104 film capacitor online today for superior EMI suppression in industrial environments. Designed for reliable performance at 300 Vac and up to 105°C, it features a flame-retardant epoxy case and polypropylene dielectric for stability and durability. Suitable for printed circuit board mounting, with supports for automatic insertion, vibration, and shock resistance ensure long-lasting operation. Purchase now to enhance your electromagnetic interference filtering solutions with a proven, quality component from Vishay.
Get Vishay BFC246840104 today—built for precision, high reliability, and effective electromagnetic interference suppression.
