Vishay IRFD9010PBF Power MOSFET
The IRFD9010PBF is a P-channel enhancement-mode power MOSFET housed in a HVMDIP package, offering very low ON-resistance, high transconductance, and rugged reliability. It is designed for reverse polarity applications and power stages with complementary N-channel devices, simplifying circuit design. Ideal for motor control, audio amplifiers, switch-mode power supplies, and pulse amplification, this device features a compact, end-stackable form factor, excellent temperature stability, and fast switching. Suitable for high-current switching, it ensures efficient operation in demanding electronic circuits.
Vishay IRFD9010PBF Power MOSFET Specifications:
- Drain-Source Voltage Vos: -50 V
- Gate-Source Voltage Vas: +20 V
- Continuous Drain Current: 0.68 A at 100°C
- Pulsed Drain Current: -88 A
- Maximum Power Dissipation: 1 W at 25°C
- Operating Junction Temperature Range: -55°C to +150°C
- Soldering Peak Temperature: 300°C for 10s
- Thermal Resistance Junction-to-Ambient: 120 °C/W
- Drain-Source Breakdown Voltage: -50 V
- Gate-Source Leakage: < 500 nA at 20 V
- On-Resistance: Max 0.50 Ω at 10 V drain voltage
- Total Gate Charge: 72 nC
- Reverse Recovery Time: 75 ns
- Body Diode Voltage: -55 V
- Rise Time: 92 ns
- Fall Time: 59 ns
Buy the Buy Vishay Siliconix IRFD9010PBF Power MOSFET Part Number IRFD9010PBF Online
Shop online now for the Vishay Siliconix IRFD9010PBF Power MOSFET, a high-performance P-channel device ideal for motor control, amplifiers, and power supplies. This MOSFET features low ON-resistance, fast switching, excellent ruggedness, and thermal stability, making it suitable for demanding applications. Its compact HVMDIP package allows easy integration into complex circuits, offering reliable reverse polarity operation. Purchase today to benefit from quick delivery and ensure optimal performance in your electronic projects and industrial applications.
Buy Vishay Siliconix IRFD9010PBF now and experience unmatched reliability and high efficiency in power switching applications.
Frequently Asked Questions
Where can I buy Vishay IRFD9010PBF?
You can click on the BUY or RFQ button to purchase IRFD9010PBF from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part IRFD9010PBF?
You can download the IRFD9010PBF datasheet or visit the Vishay website for support.
Who is the manufacturer of IRFD9010PBF?
Vishay
