Vishay F151K25Y5RP6UK5R High-Voltage Ceramic Capacitor
This ceramic capacitor features a Y5R dielectric with a voltage rating of 1500 Vdc and 1500 Vpc, suitable for high-voltage applications like snubbers and HF ballast. It offers low losses (0.2%), high capacitance in a small size, and reliable performance over a temperature range of -30°C to +125°C. The capacitor has kinked leads for easy mounting, epoxy-resin encapsulation, and is RoHS compliant. Ideal for circuits demanding high stability, low dielectric loss, and compact design, meeting IEC 60384-9 and EIA 198 standards.
Vishay F151K25Y5RP6UK5R High-Voltage Ceramic Capacitor Specifications:
- Dielectric: Y5R
- Voltage Rating: 1500 Vdc, 1500 Vpc
- Capacitance Range: 100 pF to 4700 pF
- Temperature Range: -30°C to +125°C
- Insulation Resistance: 210000 MΩ min at 500 Vdc
- Dielectric Strength: 200% of rated voltage
- Dissipation Factor: 0.2 % max.
- Lead Diameter: 0.6 mm
- Lead Spacing: 5.0 mm or 7.5 mm
- Encapsulation: Epoxy-resin, UL 94 V-0 rated
- Marking: Capacitance value, tolerance, and voltage in accordance with EIA 198
- Aging: Typical 0.5% per decade
Buy the Buy Vishay Ceramic Capacitor Part Number F151K25Y5RP6UK5R Online
Order the Vishay high-voltage ceramic capacitor F151K25Y5RP6UK5R online today to ensure reliable, low-loss performance in high-voltage applications. Designed with a Y5R dielectric, it offers a voltage rating of 1500 Vdc and 1500 Vpc, making it ideal for snubber circuits, HF ballast, and high-voltage snubber applications. Compact in size yet high in capacity, featuring kinked leads for easy mounting, epoxy-resin encapsulation for durability, and compliance with RoHS standards. Enhance your electronic design with Vishay’s trusted quality and high-performance ceramics.
Get Vishay F151K25Y5RP6UK5R today—built for high-voltage reliability and low dielectric losses in demanding circuits.
Frequently Asked Questions
Where can I buy Vishay F151K25Y5RP6UK5R?
You can click on the BUY or RFQ button to purchase F151K25Y5RP6UK5R from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part F151K25Y5RP6UK5R?
You can download the F151K25Y5RP6UK5R datasheet or visit the Vishay website for support.
Who is the manufacturer of F151K25Y5RP6UK5R?
Vishay
