Vishay F152K39S3NN63J5R Ceramic Capacitor
These ceramic disc capacitors provide high reliability, low losses, and high capacitance in a compact size, suitable for applications like SMPS, HF ballast, and high-voltage circuits. Made with ceramic dielectric Y5R or SN Y5R, they feature kinked leads, a voltage range of 500 V to 3 kV, and capacitance values from 100 pF to 4700 pF. Encased in epoxy-resin with RoHS compliance, they meet IEC and EIA standards with a temperature range of -30°C to +125°C, making them reliable for demanding electronic environments.
Vishay F152K39S3NN63J5R Ceramic Capacitor Specifications:
- Ceramic Dielectric: Y5R, SN Y5R
- Voltage (Vdc): 500 V, 1 kV, 2 kV, 3 kV
- Capacitance Range: 100 pF to 4700 pF
- Operating Temperature Range: -30 °C to +125 °C
- Dielectric Strength: 200% of rated voltage
- Insulation Resistance at 500 V: 210000 MΩ min.
- Tolerance: +10%; +20%
- Dissipation Factor: Max 0.2%
- Lead Diameter: 0.6 mm
- Lead Spacing: 5 mm or 7.5 mm
- Encapsulation: Epoxy-resin, RoHS compliant
- Marking: Capacitance value, tolerance, voltage according to EIA 198
Buy the Vishay Series F Ceramic Capacitors: F152K39S3NN63J5R
Order the Vishay ceramic capacitor F152K39S3NN63J5R online today to ensure high quality, low loss performance, and reliable operation in demanding electronic circuits. These capacitors are suitable for high-voltage applications like SMPS and high-voltage snubbers, offering excellent dielectric strength and temperature stability while meeting RoHS compliance. With a capacitance range from 100 pF to 4700 pF, rated voltages up to 3 kV, and precise lead configurations, they are ideal for engineers seeking durable and compact components for critical circuit design needs.
Buy Vishay F152K39S3NN63J5R now and experience unmatched reliability and performance for your high-voltage, low-loss electronic applications.
Frequently Asked Questions
Where can I buy Vishay F152K39S3NN63J5R?
You can click on the BUY or RFQ button to purchase F152K39S3NN63J5R from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part F152K39S3NN63J5R?
You can download the F152K39S3NN63J5R datasheet or visit the Vishay website for support.
Who is the manufacturer of F152K39S3NN63J5R?
Vishay
