Vishay F339X131048KFI2B0 interference suppression capacitor
The F339X1 series 480VAC interference suppression film capacitor features a polypropylene dielectric, metallized electrodes, and a flame-retardant epoxy resin sealed plastic case. Designed for 3-phase and across-the-line applications, it provides stable capacitance performance with a maximum temperature of 110°C and rated AC voltage of 480 Vac at 50/60 Hz. Suitable for EMC filtering and noise suppression, it complies with IEC, UL, CSA standards, ensuring reliability in harsh environments with high humidity and vibration resistance, making it ideal for industrial and electronic equipment.
Vishay F339X131048KFI2B0 interference suppression capacitor Specifications:
- Rated AC voltage: 480V
- Permissible DC voltage: 1000V
- Dielectric: Polypropylene film
- Electrodes: Metallized
- Construction: Series construction with internal series, plastic case, epoxy sealed
- Maximum temperature: 110°C
- Tolerance: ±20% (+10% on request)
- Capacitance range: 0.001 pF to 1.0 uF
- Lead pitch options: 10 mm, 15 mm, 22.5 mm, 27.5 mm
- Dimensions: varies with series and capacitance, typical length approx. 25-35 mm
- Case material: Flame-retardant epoxy resin, UL class V-0
- Lead material: Tinned wire
- Standards: IEC 60384-14, UL 60384-14, CSA-E384-14
- Vibration and shock resistant, designed for PCB mounting
- Packaging: Loose, tape and reel, or bulk depending on pitch and lead length
- Compliance: RoHS, ENEC, and CB-certifications for safety and environmental standards
Buy the Vishay Series F339X1 Interference Suppression Capacitor: 480VAC
Discover the Vishay Series F339X1 480VAC interference suppression capacitor, engineered with polypropylene dielectric and metallized electrodes for stable performance. Its flame-retardant epoxy sealed plastic case ensures safety and durability. Designed for 3-phase and across-the-line applications, it provides excellent noise suppression and EMC compliance, making it ideal for industrial environments. Easy PCB mounting with specified lead pitches, it meets international safety and environmental standards including RoHS, UL, and IEC. Reliable, high temperature resistant, and long-lasting, order online now for your project needs.
Order your Vishay Series F339X1 480VAC interference suppression capacitor today and ensure reliable noise filtering for industrial and electronic equipment.
Frequently Asked Questions
Where can I buy Vishay F339X131048KFI2B0?
You can click on the BUY or RFQ button to purchase F339X131048KFI2B0 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part F339X131048KFI2B0?
You can download the F339X131048KFI2B0 datasheet or visit the Vishay website for support.
Who is the manufacturer of F339X131048KFI2B0?
Vishay
