Vishay IHLP6767DZERR22M01 High-Current Power Inductor
High-current, low-profile shielded inductors designed for power conversion applications such as DC/DC converters, portable devices, and high-frequency circuits. They feature ultra-low DCR, handle transient spikes without saturation, and operate efficiently up to 2.0 MHz frequency range. Constructed with composite materials for ultra-low buzz noise and RoHS compliance, these inductors provide excellent performance in demanding electronic systems, supporting reliable operation in a compact, high-current package suitable for modern power supply designs.
Vishay IHLP6767DZERR22M01 High-Current Power Inductor Specifications:
- Inductance Range: 0.22 µH to 10.0 µH
- Inductance Tolerance: ±20%
- Frequency Range: Up to 2.0 MHz
- Maximum DC Current: 75.0 A for 0.22 µH, 10.0 A for 10.0 µH
- DCR: 0.80 mΩ (0.22 µH) to 25.60 mΩ (10.0 µH)
- Operating Temperature: -55°C to +125°C
- Shielded construction for reduced noise
- RoHS compliant
- Package Size: Dimensions vary from approximately 0.675 x 0.480 inches
- Material: Composite construction for low buzz noise
- Designed for high transient current without saturation
- Suitable for power management in laptops, servers, and high-frequency circuits
Buy the Vishay IHLP6767DZ – Reliable Inductors for Industrial Applications
Enhance your electronic projects with Vishay's high-current, low-profile inductors. Designed for demanding power applications, these shielded components offer ultra-low DCR, handle transient spikes effortlessly, and operate efficiently up to 2.0 MHz. Their compact size and RoHS compliance make them ideal for portable devices, high-frequency circuits, and DC/DC converters. Easily order online to ensure your systems perform reliably with premium inductors that deliver exceptional performance, durability, and efficiency for modern electrical and power management needs.
Order your Vishay Series IHLP6767DZ high-current low-profile inductors today and upgrade your power systems with dependable, efficient components.
Frequently Asked Questions
Where can I buy Vishay IHLP6767DZERR22M01?
You can click on the BUY or RFQ button to purchase IHLP6767DZERR22M01 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part IHLP6767DZERR22M01?
You can download the IHLP6767DZERR22M01 datasheet or visit the Vishay website for support.
Who is the manufacturer of IHLP6767DZERR22M01?
Vishay
