Vishay K331K15X7RK5TH5V Multilayer Ceramic Capacitor
The Vishay K Series multilayer ceramic capacitors (MLCC) are high-reliability, compact components suitable for temperature compensation, coupling, and decoupling applications. They feature dielectric types such as X7R, Y5V, and Class 1 ceramic, with capacitance ranges from 10 pF to 1,000,000 pF, and rated voltages from 50 V to 500 V. These capacitors are available in radial lead styles with straight, kinked, or crimp leads, coated with flame-retardant epoxy, and comply with RoHS standards, making them ideal for general-purpose electronics requiring stable performance over wide temperature ranges.
Vishay K331K15X7RK5TH5V Multilayer Ceramic Capacitor Specifications:
- Capacitance Range: 10 pF to 1,000,000 pF
- Rated Voltage: 50 V, 100 V, 200 V, 500 V
- Dielectric Types: X7R, Y5V, Class 1 Ceramic CoG
- Temperature Range: -55°C to +125°C (X7R), -30°C to +85°C (Y5V)
- Lead Styles: Straight, kinked, crimp, with lead spacing of 2.5 mm or 5.0 mm
- Lead Diameter: 0.5 mm, length: 30 mm ± 5 mm
- Coating: Flame-retardant epoxy resin (UL 94 V-0)
- Compliance: RoHS and JEDEC JS709A standards
- Climatic Category: 55/125/21 for Classes 1 and 2
- Marking: Capacitance and tolerance according to EIA 198 standards
Buy the Vishay Series K Capacitors: K331K15X7RK5TH5V
Discover the Vishay K Series multilayer ceramic capacitors, engineered for reliability, compact size, and high performance. These capacitors feature dielectric types such as X7R and Y5V, with voltage ratings up to 500V, making them ideal for filtering, decoupling, and temperature compensation in various electronic applications. Their robust construction with flame-retardant epoxy coating ensures safety, durability, and compliance with RoHS standards. Purchase online today for high-quality components designed to meet rigorous industry needs and enhance your electronic designs.
Get Vishay K331K15X7RK5TH5V today—built for precision and long-lasting durability in your electronic projects.
Frequently Asked Questions
Where can I buy Vishay K331K15X7RK5TH5V?
You can click on the BUY or RFQ button to purchase K331K15X7RK5TH5V from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part K331K15X7RK5TH5V?
You can download the K331K15X7RK5TH5V datasheet or visit the Vishay website for support.
Who is the manufacturer of K331K15X7RK5TH5V?
Vishay
