Vishay LTO050F22R00JTE3 Power Resistor
The LTO 50 power resistor from Vishay Sfernice features thick film technology, rated at 50 W at 25°C case temperature on heatsinks. It has a broad resistance range from 0.010 Ω to 550 kΩ, is non-inductive, and comes in a compact TO-220 package for easy mounting. The resistor offers excellent thermal stability, with a temperature coefficient as low as 150 ppm/°C, and complies with RoHS standards. Suitable for high-power applications, it ensures reliable performance over a temperature range of -55°C to +155°C, with a maximum voltage of 750 V during overloads.
Vishay LTO050F22R00JTE3 Power Resistor Specifications:
- Power Rating: 50 W at + 25°C case temperature on heatsink
- Resistance Range: 0.010 Ω to 550 kΩ
- Package: TO-220
- Maximum Voltage: 750 V during overload
- Temperature Range: -55°C to +155°C
- Thermal Resistance (component): 2.5 W at +25°C
- Temperature Coefficient: 150 ppm/°C to 900 ppm/°C depending on resistance value
- Dielectric Strength: 1500 V for 1 min
- Insulation Resistance: >10 MΩ
- Vibration Resistance: MIL-STD-202 method 308
- Climatic Category: 55/155/56
- Flammability: UL 94V-0
- Protection: Molded resistive element, alumina substrate
- Connections: Tinned copper
- Weight: maximum 2 g
- Mounting Torque: 1 Nm
- Environmental Resistance: Meets IEC 60695-11-5 standards
Buy the Vishay Series LTO Power Resistor: 50 W High-Temperature Resistance
Order the Vishay LTO 50 power resistor online now for reliable high-power performance. Designed with thick film technology, it offers a resistance range from 0.010 Ω to 550 kΩ, ensuring versatile use. Its compact TO-220 package allows easy mounting in discrete power applications. Rated at 50 W, it withstands voltages up to 750 V during overloads, and remains stable from -55°C to +155°C. Ideal for industrial, automotive, and power supply systems, buy this quality resistor online today for durable, high-performance solutions.
Get Vishay LTO 50 Power Resistor today—built for precision, high power, and long-lasting durability in your electronic designs.
Frequently Asked Questions
Where can I buy Vishay LTO050F22R00JTE3?
You can click on the BUY or RFQ button to purchase LTO050F22R00JTE3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part LTO050F22R00JTE3?
You can download the LTO050F22R00JTE3 datasheet or visit the Vishay website for support.
Who is the manufacturer of LTO050F22R00JTE3?
Vishay
