Vishay M64P202KB40 Multi-turn Cermet Trimmer
The Vishay Spectrol Model 64 is a compact, industrial-grade multi-turn cermet trimmer designed for precise PCB adjustments. It features a 3/8" x 3/8" x 3/16" size, with resistance ranging from 10 Ω to 2.2 MΩ, and offers excellent stability thanks to its cermet element. Fully sealed with IP67 rating, it withstands harsh environments, operating reliably between -55°C and +125°C. Electrical specifications include a maximum power rating of 0.5 W at 70°C, end stop torque of 1.5 N·cm, and contact resistance variation below 2%. Ideal for applications requiring fine resistance tuning in demanding conditions.
Vishay M64P202KB40 Multi-turn Cermet Trimmer Specifications:
- Size: 3/8 inch x 3/8 inch x 3/16 inch
- Resistance Range: 10 Ω to 2.2 MΩ
- Power Rating: 0.5 W at 70°C
- Temperature Range: -55°C to +125°C
- Sealing: Fully sealed IP67
- Electrical Travel: 21 turns
- Contact Resistance Variation: <2%
- End Stop Torque: 1.5 N·cm
- Dielectric Strength: 1000 V RMS
- Insulation Resistance: >10 MΩ at 600 VDC
- Terminal Material: Pure Sn
- Climatic Category: 55/125/56
- Wiper Position: Approximately 50% travel
- Mechanical Travel: 23 ±5 turns
Buy the Vishay Series Spectrol Multi-turn Cermet Trimmer: M64P202KB40
Order the Vishay Model 64 multi-turn cermet trimmer online and experience reliable performance with an IP67 sealed design, operating from -55°C to +125°C. This industrial-grade component features a resistance range of 10 Ω to 2.2 MΩ, with a power rating of 0.5 W at 70°C, ensuring precise and stable resistance adjustments. Its compact size makes it ideal for demanding applications requiring high accuracy in tight spaces. Buy online now to enhance your electronic and industrial projects with a durable, high-quality trimmer designed for long-term use.
Get Vishay Model 64 multi-turn cermet trimmer today—built for precise resistance tuning and long-lasting durability.
Frequently Asked Questions
Where can I buy Vishay M64P202KB40?
You can click on the BUY or RFQ button to purchase M64P202KB40 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part M64P202KB40?
You can download the M64P202KB40 datasheet or visit the Vishay website for support.
Who is the manufacturer of M64P202KB40?
Vishay
