Vishay M64P503KB40 Multi-Turn Cermet Trimmer
The Vishay Spectrol M64P503KB40 is a compact 3/8-inch square (10 mm) multi-turn cermet trimmer designed for precise PC board adjustments. Featuring excellent operational stability due to its cermet resistive element, it supports resistance ranges from 10.9Ω to 2.2MΩ with 5% or 10% tolerance options. This industrial-grade component offers a maximum power rating of 0.5W at +70°C, with a fully sealed IP67 design suitable for harsh environments. It includes mechanically durable terminals, a temperature range from -55°C to +125°C, and a maximum voltage of 250V, ensuring reliable long-term performance for resistive trimming applications.
Vishay M64P503KB40 Multi-Turn Cermet Trimmer Specifications:
- Resistive element: Cermet
- Resistance range: 10.9Ω to 2.2MΩ
- Tolerance: 5% or 10%
- Power rating: 0.5W at +70°C
- Operating temperature: -55°C to +125°C
- Dielectric strength: 1000V RMS
- Insulation resistance: >10 MΩ (600V DC)
- End resistance: 12Ω typical
- Mechanical travel: 23 turns ±5
- Maximum voltage: 250V
- Sealing: Fully sealed IP67
- Terminal material: Pure Sn
- Weight: Approx. 0.82g
- Dimensions: 3/8
Buy the Buy Vishay Spectrol Multi-Turn Cermet Trimmer Part Number M64P503KB40 Online
Order the Vishay Spectrol M64P503KB40 online now to ensure reliable, high-precision PC board adjustments. This industrial-grade, fully sealed IP67 trimmer features a resistive range of 10.9Ω to 2.2MΩ, with a power rating of 0.5W at +70°C. Designed to operate from -55°C to +125°C, it offers excellent stability, a maximum voltage of 250V, and durable pure Sn terminals. Perfect for harsh environments requiring accurate resistance adjustments with long-term reliability.
Get Vishay Spectrol M64P503KB40 today—built for precision and long-lasting durability in resistive trimming applications.
Frequently Asked Questions
Where can I buy Vishay M64P503KB40?
You can click on the BUY or RFQ button to purchase M64P503KB40 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part M64P503KB40?
You can download the M64P503KB40 datasheet or visit the Vishay website for support.
Who is the manufacturer of M64P503KB40?
Vishay
