Vishay M64X203KB40 Multi-turn Trimmer Resistor
The 64X203KB40 is a high-quality, industrial-grade 3/8-inch square multi-turn cermet trimmer resistor designed for precise calibration and tuning in industrial applications. It features a 2.2 Megaohm resistance range, 10% standard tolerance, and robust sealing to IP67 standards. This trimmer offers excellent stability, linear resistance change, and a maximum power rating of 0.5W at +70°C. Its compact size and fully sealed construction make it suitable for demanding environments requiring accurate resistance adjustment and durable performance.
Vishay M64X203KB40 Multi-turn Trimmer Resistor Specifications:
- Dimensions: 3/8" x 3/8" x 3/16" (approx. 9.5 mm x 9.5 mm x 4 mm)
- Resistance Range: 10 Ω to 2.2 MΩ
- Resistance Tolerance: 10%
- Power Rating: 0.5W at +70°C
- Temperature Range: -55°C to +125°C
- Sealing: Fully sealed IP67
- Resistive Element: Cermet
- Electrical Travel: 21 turns
- Max End Stop Torque: 1.5 N·cm
- Dielectric Strength: 1000 V RMS
- Insulation Resistance: > 10 MΩ at 600 V
- Wiper: Positioned at approx. 50%
- Mechanical Travel: 23 turns ±5
- Clutch Action: Yes
- Terminal Material: Pure Sn
- Vibration Resistance: 10 g for 6 hours
- Shock Resistance: 0.1% variation after 8 shocks in 3 directions
Buy the Vishay 64X203KB40 – Reliable Multi-Turn Cermet Trimmer for Industrial Applications
Purchase the Vishay 64X203KB40 today to ensure precise resistance calibration with this compact, sealed IP67 multi-turn cermet trimmer resistor. Designed for industrial applications, it provides excellent stability, linear resistance change, and durability in harsh environments. With a resistance range up to 2.2 Megaohms, a power rating of 0.5W, and operating temperatures from -55°C to +125°C, this high-performance component is ideal for calibrating electronic circuits requiring accurate and reliable resistance adjustments. Order online now for fast delivery.
Get Vishay 64X203KB40 today—built for precision and long-lasting durability in demanding industrial environments.
Frequently Asked Questions
Where can I buy Vishay M64X203KB40?
You can click on the BUY or RFQ button to purchase M64X203KB40 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part M64X203KB40?
You can download the M64X203KB40 datasheet or visit the Vishay website for support.
Who is the manufacturer of M64X203KB40?
Vishay
