Vishay M64Z502KB40 Multi-turn Cermet Trimmer
The Model 64 is a compact, industrial-grade multi-turn cermet trimmer designed for PCB mounting, offering excellent stability, 21 turns of travel, and a resistance range of 10.9 to 2.2 MΩ. It features a fully sealed IP67 housing, high dielectric strength, and a temperature range of -55°C to +125°C. Ideal for precision adjustments in electronic and industrial applications, it provides reliable performance with a resistive element made of cermet, suitable for various environments and demanding conditions.
Vishay M64Z502KB40 Multi-turn Cermet Trimmer Specifications:
- Resistive element: Cermet
- Resistance range: 10.9 to 2.2 MΩ
- Power rating: 0.5 W at 70°C
- Tolerance: Standard 10%, on request 5%
- Temperature coefficient: See standard resistance table, ppm/°C varies with resistance value
- Mechanical travel: 21 turns ± 5
- Mechanical dimensions: 3/8'' x 3/8'' x 3/16'' (in millimeters: approximately 9.7 x 9.7 x 4.8)
- Operating torque (max): 1.5 N·cm
- End resistance (typical): 12 Ω
- Dielectric strength: 1000 V RMS
- Insulation resistance: > 10 MΩ at 600 V DC
- Temperature range: -55°C to +125°C
- Sealing: Fully sealed, IP67
- Wiper: Positioned at approx. 50% travel
- Terminal: Pure Sn finish
- Terminal spacing: 9.7 mm
- Weight: Approx. 0.82 g
Buy the Vishay 64Z502KB40 – Reliable Multi-Turn Cermet Trimmer for Industrial Applications
Order Vishay 64Z502KB40 online today—this high-quality, sealed IP67 trimmer features 21 turns, resistance up to 2.2 MΩ, and operates reliably from -55°C to +125°C. Perfect for industrial electronics requiring precise, stable adjustments, its rugged construction ensures durability and consistent performance in harsh conditions. Whether in automation, control systems, or electronic calibration, this multi-turn trimmer provides accuracy and stability, backed by a trusted manufacturer. Buy now and optimize your electronic projects with confidence.
Get Vishay 64Z502KB40 today—designed for precise adjustments and long-lasting durability in demanding environments.
